ADSP-BF504

Low Cost Blackfin with Optimized Peripheral Set for Industrial and General Purpose Applications

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Models 2
1ku List Price Starting From $7.33
Features
  • Blackfin processor core with 400 MHz (800 MMACS) performance and 68KB L1 Memory
  • Low power dissipation
  • Two SPI, two SPORT, two UART and one PPI interface
  • ADC Control Module for glue-less interface to an external ADC with synchronized sampling
  • Two 3-phase PWM units
  • CAN Controller and Removable Storage Interfaces
  • Eight general purpose counters and two 32-bit up/down counters with rotary support
  • Twelve peripheral DMA channels and two memory to memory DMA channels
  • 12 × 12mm LFCSP package
  • Commercial and industrial temperature grades
Additional Details
show more Icon

The BF504 is a low cost member of the Blackfin portfolio of processors. With a 400 MHz core clock speed and a unique peripheral set including two three-phase PWM units, an ADC Control Module, two SPI’s, two SPORT’s, a CAN controller, a PPI, eight general purpose counters and a Removable Storage Interface, the BF504 is feature and cost optimized for compute intensive industrial and general purpose applications that do not require external memory or executable flash. The BF504 is offered in a low cost 12 × 12mm LFCSP package in commercial and industrial temperature grades.
