AD5270

1024-Position, 1% Resistor Tolerance Error, SPI Interface and 50-TP Memory Digital Rheostat

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 8
1ku List Price Starting From $1.93
Features
  • Single-channel, 1024-/256-position resolution
  • 20 kΩ, 50 kΩ and 100 kΩ nominal resistance
  • Maximum ±1% nominal resistor tolerance error
  • 50-times programmable (50-TP) wiper memory
  • Rheostat mode temperature coefficient: 5 ppm/°C
  • 2.7 V to 5.5 V single-supply operation
  • ±2.5 V to ±2.75 V dual-supply operation for ac or bipolar operations
  • SPI-compatible interface
  • Wiper setting readback
  • Power on refreshed from 50-TP memory
  • Thin LFCSP, 10-lead, 3 mm × 3 mm × 0.8 mm package
  • Compact MSOP, 10-lead, 3 mm × 4.9 mm × 1.1 mm package
Additional Details
show more Icon

The AD5270 / AD5271 are single-channel, 1024-/256-position digital rheostats that combine industry leading variable resistor performance with nonvolatile memory (NVM) in a compact package.

The AD5270 / AD5271 ensure less than 1% end-to-end resistor tolerance error and offer 50-times programmable (50-TP) memory.

The guaranteed industry leading low resistor tolerance error feature simplifies open-loop applications as well as precision calibration and tolerance matching applications.

The AD5270 / AD5271 device wiper settings are controllable through the SPI digital interface. Unlimited adjustments are allowed before programming the resistance value into the 50-TP memory. The AD5270/AD5271 do not require any external voltage supply to facilitate fuse blow and there are 50 opportunities for permanent programming. During 50-TP activation, a permanent blow fuse command freezes the resistance position (analogous to placing epoxy on a mechanical trimmer).

The AD5270 / AD5271 are available in a 3 mm x 3 mm, 10-lead LFCSP package and in a 10-lead MSOP package. The parts are guaranteed to operate over the extended industrial temperature range of −40°C to +125°C.

APPLICATIONS

  • Mechanical potentiometer replacements
  • Op-amp: variable gain control
  • Instrumentation: gain, offset adjustment
  • Programmable voltage-to-current conversions
  • Programmable filters, delays, time constants
  • Programmable power supply
  • Sensor calibration
Part Models 8
1ku List Price Starting From $1.93

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
AD5270BCPZ-100-RL7
  • HTML
  • HTML
AD5270BCPZ-20-RL7
  • HTML
  • HTML
AD5270BRMZ-100
  • HTML
  • HTML
AD5270BRMZ-100-RL7
  • HTML
  • HTML
AD5270BRMZ-20
  • HTML
  • HTML
AD5270BRMZ-20-RL7
  • HTML
  • HTML
AD5270BRMZ-50
  • HTML
  • HTML
AD5270BRMZ-50-RL7
  • HTML
  • HTML

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Dec 14, 2010

- 10_0354

AD5270 AD5271 Data Sheet Correction to prevent SDO pin malfunction.

AD5270BCPZ-100-RL7

PRODUCTION

AD5270BCPZ-20-RL7

PRODUCTION

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Mar 22, 2021

- 21_0001

Addition of Amkor Philippines as an Alternate Site for Singulated MSOP and MSOP_EP

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Oct 30, 2017

- 15_0176

Assembly Transfer of Select 8/10L MSOP Products to Amkor Philippines

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

May 15, 2012

- 10_0006

Halogen Free Material Change for mini SOIC Products

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Dec 14, 2010

- 10_0354

arrow down

AD5270 AD5271 Data Sheet Correction to prevent SDO pin malfunction.

AD5270BCPZ-100-RL7

PRODUCTION

AD5270BCPZ-20-RL7

PRODUCTION

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Mar 22, 2021

- 21_0001

arrow down

Addition of Amkor Philippines as an Alternate Site for Singulated MSOP and MSOP_EP

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Oct 30, 2017

- 15_0176

arrow down

Assembly Transfer of Select 8/10L MSOP Products to Amkor Philippines

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

May 15, 2012

- 10_0006

arrow down

Halogen Free Material Change for mini SOIC Products

AD5270BRMZ-100

PRODUCTION

AD5270BRMZ-100-RL7

PRODUCTION

AD5270BRMZ-20

PRODUCTION

AD5270BRMZ-20-RL7

PRODUCTION

AD5270BRMZ-50

PRODUCTION

AD5270BRMZ-50-RL7

PRODUCTION

Evaluation Kit

Evaluation Kits 2

reference details image

EVAL-AD5270

AD5270 Evaluation Board

zoom

EVAL-AD5270

AD5270 Evaluation Board

AD5270 Evaluation Board

Features and Benefits

  • Full-featured evaluation board for the AD5270
  • 4-wire ohm measurement capability
  • Various link options
  • PC control via a separately purchased system demonstration platform (SDP)
  • PC software for control
  • 50-times programmable (50-TP)
  • 1% resistance tolerance error

Product Detail

The AD5270 is a single-channel, 1024-position digital rheostat with less than ±1% end-to-end resistor tolerance error and 50-time programmable memory.


The AD5270 supports a dual-supply ±2.5 V to ±2.75 V operation and a single-supply 2.7 V to 5.5 V operation, making it suited for battery-powered applications and many other applications.


The AD5270 uses a versatile 3-wire serial interface that operates at clock rates up to 50 MHz, and it is compatible with standard SPI, QSPI™, MICROWIRE™, and DSP interface standards.


The EVAL-AD5270SDZ evaluation board can operate in single-supply and dual-supply mode and incorporates an internal power supply from the USB.


Complete specifications for the AD5270 can be found in the UG-094 datasheet.

reference details image

EVAL-CN0357-ARDZ

Arduino Compatible Electrochemical Gas Detection Circuit (CN0357)

zoom

EVAL-CN0357-ARDZ

Arduino Compatible Electrochemical Gas Detection Circuit (CN0357)

Arduino Compatible Electrochemical Gas Detection Circuit (CN0357)

Features and Benefits

  • Form Factor Compatible with Arduino
  • Programmable for multiple other gases
  • Resolution down to 1ppm
  • Low power, single supply operation

Product Detail

CN0357 single-supply, low noise, portable gas detector circuit using an electrochemical sensor. The Alphasense CO-AX carbon monoxide sensor is used in this example. Electrochemical sensors offer several advantages for instruments that detect or measure the concentration of many toxic gases. Most sensors are gas specific and have usable resolutions under one part per million (ppm) of gas concentration.
