MAX74822

RECOMMENDED FOR NEW DESIGNS

5V, CMOS, Rail-to-Rail, General-Purpose Amplifiers

Data Sheet (Rev. 0) Product Selection Table

Part Models: 3
1ku List Price: Starting From $0.30

Viewing:

Overview

Single-supply operation: 2.7V to 5.5V
Low supply current: 45μA/amplifier
Wide bandwidth: 1MHz
No phase reversal

Low input bias current: 4pA
Unity gain stable
Rail-to-rail input and output

Part Models: 3
1ku List Price: Starting From $0.30

Documentation

Data Sheet 1

MAX74822: 5V, CMOS, Rail-to-Rail, General-Purpose Amplifiers Data Sheet (Rev.0) 11/04/2025

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX74822ARMZ	8-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
MAX74822ARMZ-R7	8-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys
MAX74822ARMZ-RL	8-Lead MSOP	Material Declaration Reliability Report Package Resources	Ultra Librarian SamacSys

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
AD8542	PRODUCTION	CMOS Rail-to-Rail General-Purpose Amplifiers

Tools & Simulations

LTspice

Models for the following parts are available in LTspice:

MAX74822

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.

Evaluation Kits

EVAL-OPAMP-2 Evaluation Board

Buy Now View Details

Product Details

The universal precision op amp evaluation boards have been designed and optimized for many circuit configurations allowing the users to best suit their applications. These boards are all RoHs compliant. See references below on what board to order by lead count and package.

EVAL-PRAOPAMP-2CPZ (dual 8-lead LFCSP) CP-8
EVAL-PRAOPAMP-2RMZ (dual 8-lead MSOP) RM-8
EVAL-PRAOPAMP-2RZ (dual 8-lead SOIC) R-8
