REF02

不推荐用于新设计

+5V、+10V精密电压基准

数据手册 (Rev. 7)

产品选型表

产品模型: 16

Viewing:

概述

Pretrimmed to +5V, +10V
Excellent Temperature Stability: 3ppm/°C (typ)
Low Noise: 10µV_P-P (REF02)
Short-Circuit Protected
Linear Temperature Transducer Output (REF02)

应用

模数转换器
数字电压表
数模转换器
门限检测器
稳压器

产品模型: 16

参考资料

数据手册 3

REF01-REF02: +5V, +10V Precision Voltage References Data Sheet (Rev.7) 04/19/2007

1403: +5V、+10V精密电压基准 Data Sheet 01/01/1900

REF02 10/10/2022

技术文章 3

选择最佳的电压基准源 04/13/2004

Reduce the Chances of Human Error: Part 2, Super Amps and Filters for Analog Interface 03/08/2011

Selecting the Right Series Voltage Reference for Absolute-Accuracy Voltage-Output DAC Designs 07/22/2002
