LTC2656

具10ppm/ºC 最大值基准的八通道、12 位、轨至轨 DAC

更多 showmore-icon

Info: : 量产 tooltip
Info: : 量产 tooltip
查看： 产品详情
arrow-icon
产品详情

不是您想寻找的产品？

viewall 去产品选项表
file 查看数据手册
Documentation 查看所有文档
Linduino LTC2656 Linduino .CPP File Download 5.00KB Linduino LTC2656 - DC1397A Linduino .INO File Download 26.00KB Linduino LTC2656 Linduino Header File Download 8.00KB IBIS 模型 LTC2656 IBIS Model Download 101.00KB
产品模型 40
特性
  • 精准10ppm/ºC 最大值基准
  • 最大 INL 误差：±4LSB (在 16 位)
  • 在整个温度范围内保证单调
  • 可选择的内部或外部基准
  • 2.7V 至 5.5V 电源范围 (LTC2656-L)
  • 集成基准缓冲器
  • DAC 之间的超低串扰 (<1nV•s)
  • 上电复位至零标度 / 中间标度
  • 异步 LDAC 更新引脚
  • 纤巧型 20 引脚 4mm x 5mm QFN 封装和 20 引脚耐热性能增强型 TSSOP 封装



更多细节
show more Icon

LTC®2656 是一个 8 通道 16 位 / 12 位轨至轨 DAC 系列，具有一个精准的集成基准。这些 DAC 具有内置的高性能、轨至轨输出缓冲器，并保证具有单调特性。LTC2656-L 具有一个 2.5V 的全标度输出和集成 10ppm/ºC 基准，并采用 2.7V 至 5.5V 工作电源。LTC2656-H 具有一个 4.096V 的全标度输出和集成基准，并采用 4.5V 至 5.5V 的单工作电源。每个 DAC 也可以采用一个外部基准来运作，该外部基准负责将 DAC 全标度输出设定为外部基准电压的两倍。

这些 DAC 通过一个 SPI / MICROWIRE™ 兼容型四线式串行接口进行通信，该接口在高达 50MHz 的时钟频率条件下工作。LTC2656 包括一个受控于 PORSEL 引脚的上电复位电路。如果 PORSEL 引脚连接至 GND，则 DAC 被复位至零标度。如果 PORSEL 引脚连接至 VCC，则 DAC 将复位至中间标度。




Applications

  • 移动通信
  • 过程控制和工业自动化
  • 仪表
  • 自动测试设备
