CM4xx Mixed-Signal Control Processors

Analog Devices ADSP-CM4xx mixed-signal control processors utilize the ARM®-Cortex™ M4 processor core integrated with high precision A/D converters, digital accelerators and filters, SRAM and flash memories, and a rich set of peripherals. The processors are suitable for a wide myriad of embedded applications requiring high performance, real-time control, and analog conversion.
Product Selection Table

CM4xx Mixed Signal Control Processors

  Hold Shift Key for secondary sorting
SortOrderPart#Clock Speeds AvailableADC ENOB (typ)
(bits)
ADC ChannelsMemory SRAM on chipMemory Flash on chipUSBSerial Comms PortsEthernet Protocal SupportedMemory Ext Types SupportedGPIO pinsSpecial FeaturesADC SamplingUS Price 1000 to 4999
($ US)
1ADSP-CM419F 240 MHz 14 31 160 kB 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 6 Way-
2ADSP-CM418F 240 MHz 12 31 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 6 Way-
3ADSP-CM417F 240 MHz 14 24 160 kB 1 MB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 3 Way-
4ADSP-CM416F 240 MHz 12 24 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 CORDIC, Enhanced PWM, FFT Arching Detection, FOCP, HAE, Math Function Block, SINC filters 4, SMC 3 Way-
5ADSP-CM413F 240 MHz 14 24 128 kB, 160 kB 256 kB, 512 kB- 1 I2C, 2 CAN, 2 SPI, 3 UARTS No 16 bit EMIF 73 Enhanced PWM, FOCP, Math Function Block, SINC filters 4, SMC 3 Way-
6ADSP-CM411F 180 MHz, 240 MHz 12 24- 256 kB No 1 I2C, 2 CAN, 2 SPI, 5 UARTs No 16 bit EMIF 73 Enhanced PWM, FOCP, Math Function Block, SINC filters 4, SMC 3 Way-
7ADSP-CM409F 240 MHz 14 24 384 kB 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $14.05
8ADSP-CM403F-F 100 MHz 14 24- 256 kB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $9.39
9ADSP-CM403F-E 150 MHz 14 24--- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $9.70
10ADSP-CM403F-C 240 MHz 14 24- 2 MB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $11.89
11ADSP-CM403F 150 MHz, 240 MHz 14 24 384 kB 2 MB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $9.39
12ADSP-CM402F-F 100 MHz 12 24- 256 kB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
13ADSP-CM402F-E 150 MHz 12 24--- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $8.76
14ADSP-CM402F 100 MHz, 150 MHz 11 24 128 kB 512 kB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 40 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
15ADSP-CM408F-B 240 MHz 14 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $13.15
16ADSP-CM408F-A 240 MHz 14 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $13.77
17ADSP-CM408F 240 MHz 13 16 384 kB 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Optional 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $13.15
18ADSP-CM407F-D 150 MHz 12 16- 1 MB- 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
19ADSP-CM407F-B 240 MHz 12 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS- 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $11.89
20ADSP-CM407F-A 240 MHz 12 16- 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Yes 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $12.52
21ADSP-CM407F 150 MHz, 240 MHz 11 16 384 kB 2 MB Yes 1 I2C, 2 CAN, 3 UARTS Optional 16 bit EMIF 91 HAE, PWM Units, QEP 2, SINC filters 4- $8.14
