Single-Ended Amplifiers (Op-Amp)

For designs requiring single-ended amplifiers (op amps), Analog Devices' portfolio of high speed op amps and precision op amps provides a broad choice of products that deliver unmatched performance. Explore op amps by parameters, and find expert system-level advice on design problems with our amplifier reference designs (Circuits from the Lab®), design tools, selection guides, calculators, and SPICE models.
Product Selection Table

Single-Ended Amplifiers (Op-Amp)

Single-Ended Amplifiers (Op-Amp)

Click to see all in Parametric search

Single-Ended Amplifiers (Op-Amp)

Part#Amps per PackageFeedback Type-3dB Bandwidth at min gain (typ)GBP (typ)Slew Rate (typ)Voltage Noise Density (typ)Shutdown/DisableVsupply Span (min)Vsupply Span (max)Vos (typ)Iq/Amp (typ)US Price 1000 to 4999Type of Amplifier
ADA4805-2 2 Voltage 120 MHz 30 MHz 190 V/µs 5.2 nV/rtHz Yes 2.7 10 13 µV 570 µA $1.64 Buffer, High Speed, Single-Ended Amplifiers- Op-Amp
ADA4805-1Reference Circuit Available 1 Voltage 120 MHz 30 MHz 190 V/µs 5.2 nV/rtHz Yes 2.7 10 13 µV 570 µA $0.95 Buffer, High Speed, Single-Ended Amplifiers- Op-Amp
ADA4817-2Reference Circuit Available 2 Voltage 1.05 GHz 410 MHz 870 V/µs 4 nV/rtHz No 5 10 400 µV 21 mA $4.98 FET Input, High Speed, Single-Ended Amplifiers- Op-Amp
ADA4817-1 1 Voltage 1.05 GHz 410 MHz 870 V/µs 4 nV/rtHz Yes 5 10 400 µV 21 mA $2.95 FET Input, High Speed, Single-Ended Amplifiers- Op-Amp
AD8275Reference Circuit Available 1- - - - 40 nV/rtHz- 3.3 15 500 µV - $1.60 Difference Amplifier, Single-Ended Amplifiers- Op-Amp
ADA4841-2 2 Voltage 80 MHz 30 MHz 13 V/µs 2.1 nV/rtHz No 2.7 12 40 µV 1.2 mA $2.32 BiPolar, High Speed, Single-Ended Amplifiers- Op-Amp
ADA4841-1Reference Circuit Available 1 Voltage 80 MHz 30 MHz 13 V/µs 2.1 nV/rtHz Yes 2.7 12 40 µV 1.2 mA $1.59 BiPolar, High Speed, Single-Ended Amplifiers- Op-Amp
AD8021Reference Circuit Available 1 Voltage 490 MHz 1 GHz 150 V/µs 2.1 nV/rtHz Yes 4.5 24 400 µV 7.7 mA $1.31 BiPolar, High Speed, Single-Ended Amplifiers- Op-Amp, Video Amplifiers
