RH07

Obsolete

Operational Amplifier

Viewing:

Overview

ABSOLUTE MAXIMUM RATINGS
Supply Voltage: ±22V
Differential Input Voltage: ±30V
Input Voltage: ±22V
Output Short-Circuit Duration (Note 3): Indefinite
Operating Temperature Range: –55°C to 125°C
Storage Temperature Range: –65°C to 150°C
Lead Temperature (Soldering, 10 sec): 300°C

The RH07 is a precision op amp which provides very low offset voltage, low drift and low noise. In the design, processing and testing of the device, particular attention has been paid to the optimization of the entire distribution of several key parameters. The wafer lots are processed to LTC’s in-house Class S flow to yield circuits usable in stringent military applications.

For complete electrical specifications, performance curves, application notes and applications circuits, see the OP-07 data sheet.
