MAX96716A

RECOMMENDED FOR NEW DESIGNS

Dual GMSL2 to CSI-2 Deserializer

Data Sheet (Rev. 5) Product Selection Table
Viewing:

Overview

  • Full-Duplex Capability over a Single Coax or STP Cable
    • 3Gbps or 6Gbps Forward Link Rates
    • 187.5Mbps Reverse Link Rate
  • Dual Four-Lane D-PHY or Dual Two-Lane C-PHY MIPI CSI-2 v1.3 Output Ports
    • Aggregation and Replication Functions
    • 16 Virtual Channel Support
    • Supports RAW8/10/12/14/16/20, RGB565/666/888, YUV422 8-/10-Bit, User-Defined and Generic Long-Packet Data Types
  • Advanced MIPI D-PHY v1.2 Transmitters
    • 80Mbps to 2.5Gbps per Lane
  • Advanced MIPI C-PHY v1.0 Transmitters
    • 182Mbps to 4.56Gbps per Lane
  • Reference-over-Reverse (RoR) Channel Supports Crystal-Free Operation of Serializer
  • ASIL-Relevant Functional-Safety Features
    • ASIL-B Compliant
    • End-to-End Data Integrity Through CRC in Tunnel Mode
    • R-S FEC for Protection of Forward Video and Control-Channel Data
    • 16-Bit CRC Protection of Side-Channel Data (I2C, UART, SPI, GPIO) with Retransmission upon Error Detection
    • 32-Bit CRC Protection of Video Line Data
  • Forward- and Reverse-Channel PRBS for BER Testing of Serial Link
  • Continuous Link-Margin Monitoring and Optimization
    • Continuous Adaptive Equalization
    • Forward and Reverse Channel Eye-Opening Monitor for Continuous Link Margin Diagnosis
  • Concurrent Side-Channel for Device Configuration and Communication with Peripherals
    • I2C/UART, Pass-Through I2C/UART, SPI, GPIO, and Register-Programmable GPIO
    • Four Hardware-Programmable Device Addresses
  • 48-Lead 7mm x 7mm TQFN Side-Wettable Package with 0.5mm Lead Pitch

The MAX96716A converts dual GMSL2 serial inputs to MIPI CSI-2. It also transmits and receives control-channel data, enabling transmission of forward-path video and bidirectional control data. The GMSL2 link operates at a fixed rate of 6Gbps or 3Gbps in the forward direction, and 187.5Mbps in the reverse direction.

The GMSL™ inputs operate independently, allowing video with different timing and resolution to be received on each input.

Video data from both inputs can be aggregated for output on a single CSI-2 port or replicated on a second port for redundant processing.

The device and connected serializer are programmed through I2C or UART.

Operation is specified over the automotive temperature range of -40°C to +105°C and the device is AEC-Q100 qualified.

Data may be transmitted over low-cost 50Ω Coax or 100Ω STP cables that meet the GMSL2 channel specification. Contact the factory for the GMSL2 channel specification.

Table 1. Typical Maximum Cable Length vs. Attenuation
  3.2mm Ø 50Ω Coax, Foam Dielectric 2.7mm Ø 50Ω Coax, Solid Dielectric 100Ω Shielded-Twisted Pair, AWG26
Attenuation at 3GHz (Typ, Room Temp) 0.9dB/m 1.6dB/m 1.8dB/m
Attenuation at 3GHz (Max, Aged, +105°C) 1.1dB/m 2.0dB/m 2.2dB/m
GMSL Fwd/Rev Data Rate Typical Maximum Cable Length at +105°C
3Gbps/187.5Mbps 20m 10m 11m
6Gbps/187.5Mbps 15m 9m 8m

Applications

  • ADAS (2MP+/4MP 60fps) Camera Systems
  • Satellite LiDAR and RADAR Systems
  • 8MP 40fps Forward-Vision Camera (FVC) Systems
  • Surround-View Systems (SVS)
  • Driver-Monitor Systems (DMS)
  • Systems with Multiple Synchronized Cameras
MAX96716A
Dual GMSL2 to CSI-2 Deserializer
MAX96716A Functional Block Diagram MAX96716A Pin Configuration
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

User Guide 4

Application Note 1

Spec Notice 1

Learn More
Add to myAnalog

Add media to the Resources section of myAnalog, to an existing project or to a new project.

Create New Project

Tools & Simulations

Software Development 2

IBIS Model 1

Evaluation Kits

eval board
schematic 1
schematic 2
schematic 3
MAX96716/MAX96792 DPHY Evaluation Kit

Evaluation Kit for MAX96716A, MAX96716F, and MAX96792A

Buy Now View Details

Features and Benefits

  • Deserialzier Accepts GMSL2 or GMSL3 (depending on variant) Data Through Coaxial FAKRA or Differential HMTD Connectors and Converts to MIPI DPHY V1.2 Output.
  • Windows 10-Compatible Software Support
  • Powerful, Simple-to-Use GUI for Comprehensive Device Feature Evaluation
  • USB-Controlled Interface (Cable Included)
  • Board Powered by USB, 12V Wall Adapter, or External Power Supply
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Details

The MAX96716 and MAX96792 evaluation kits (EV kits) provide a reliable platform for evaluating ADI devices MAX96716A, MAX96716F, and MAX96792A through the use of standard FAKRA coaxial cables or HMTD cable. These deserializer devices support high-bandwidth, gigabit, multimedia (GMSL) serial links and offer spread spectrum and full-duplex control channel features. The EV kit includes a simple-to-use Windows 10-compatible graphical user interface (GUI) for exercising device features.

In the following sections, the term deserializer refers to the MAX96716 and MAX96792A and any of the devices listed above. The term serializer refers to any GMSL2 serializer device, particularly the MAX96717. If using the MAX96792A in GMSL3 mode, the companion Serializer is MAX96793.

For complete GMSL2 or GMSL3 evaluation using a standard FAKRA coax cable or HMTD cable, order the MAX96716/MAX96792 COAX/STP EV kit along with a companion serializer board (MAX96717/MAX96793 COAX/STP EV kit is referenced in this document). For a detailed look at all GMSL2 features, including information on how to use the parts, refer to the GMSL2/GMSL3 User’s Guide (GMSL2/GMSL3_Users_Guide_vXX, found in Maxim’s GMSL customer portal folder)..

eval board
schematic 4
schematic 5
schematic 6
schematic 7
AD-GMSL716MIPI-EVK

GMSL2-to-MIPI Deserializer Board for SoC Camera Systems

Buy Now View Details

Features and Benefits

  • 2 × MIPI CSI-2 22P (4 × lanes) ribbon cable connectors
  • 2 × GMSL2 input connectors
  • Power over Coax implementation, 12V, 1.2A total output
  • Input power selection between USB-C 5V or 6-pin connector
  • Compatible with NVIDIA Jetson, Raspberry Pi, and AMD SoC platforms
  • Mounting holes for secure attachment as a shield to Raspberry Pi
  • Small form-factor design for space-constrained applications

Product Details

The AD-GMSL716MIPI-EVK is a compact, cost-effective GMSL2 deserializer evaluation board that bridges GMSL2 serialized video signals to MIPI CSI-2 interfaces for system-on-chip (SoC) platforms. Featuring the MAX96716A dual GMSL2 to CSI-2 deserializer, this board provides a robust solution for automotive and industrial vision applications.

The board addresses the market need for affordable GMSL camera solutions covering multiple sensor types. It implements Power over Coax functionality, allowing both data transmission and power delivery through a single coaxial cable, significantly simplifying system integration and cable management. The evaluation board includes comprehensive reference software with device tree and Linux images for all supported camera types.

Key technical capabilities include support for up to 15-meter cable lengths, 3Gbps or 6Gbps forward link rates, and bidirectional I2C communication for camera control. The board's small form factor and mounting compatibility make it ideal for rapid prototyping and development of GMSL2 camera systems.

APPLICATIONS

  • Advanced Driver Assistance Systems (ADAS)
  • Mobile and mounted robotics
  • Autonomous vehicles and automotive cameras
  • Outdoor machines and industrial equipment
  • Smart and flexible manufacturing systems
  • Security and surveillance systems
  • Industrial automation and machine vision
MAX96716/MAX96792 DPHY Evaluation Kit
Evaluation Kit for MAX96716A, MAX96716F, and MAX96792A
MAX96716EVKIT Board Photo Angle View MAX96716EVKIT Board Photo Top View MAX96716EVKIT Board Photo Bottom View
AD-GMSL716MIPI-EVK
GMSL2-to-MIPI Deserializer Board for SoC Camera Systems
AD-GMSL716MIPI-EVK Board Photo Angle View AD-GMSL716MIPI-EVK Board Photo Top View AD-GMSL716MIPI-EVK Board Photo Bottom View AD-GMSL717MIPI-EVK Block Diagram
