MAX690

PRODUCTION

Microprocessor Supervisory Circuits

Industry-Standard, Full-Function µP Supervisor

Data Sheet (Rev. 5) Product Selection Table

Part Models: 5
1ku List Price: Starting From $5.99

Viewing:

Part Details

Supervisory Function Integration Saves Board Space while Fully Protecting Microprocessor-Based Systems
- Precision Voltage Monitor
  - 4.65V (MAX690, MAX691, MAX694, MAX695)
  - 4.40V (MAX692, MAX693)
- Power OK/Reset Time Delay
  - 50ms, 200ms, or Adjustable
- Watchdog Timer
  - 100ms, 1.6s, or Adjustable
- Battery Backup Power Switching
- Voltage Monitor for Power Fail or Low Battery Warning
- Minimum External Component Count
Low Power Consumption in Battery Backup Mode Extends Battery Life
- 1µA Standby Current
Onboard Gating of Chip Enable Signals Protects Against Erroneous Data Written to RAM During Low V_CC Events

Part Models: 5
1ku List Price: Starting From $5.99

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX690CPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX690EJA	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX690EPA+	Plastic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX690MJA	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys
MAX690MJA/883B	Ceramic Dual-In-Line, Narrow (0.3in)	Material Declaration Reliablity Data	Ultra Librarian SamacSys

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts	Product Life Cycle	Description
Supervisory Circuits & Reset ICs 7
MAX6361	PRODUCTION	SOT23, Low-Power Microprocessor Supervisory Circuits with Battery Backup
MAX6362	PRODUCTION	SOT23, Low-Power Microprocessor Supervisory Circuits with Battery Backup
MAX6363	PRODUCTION	SOT23, Low-Power Microprocessor Supervisory Circuits with Battery Backup
MAX6364	PRODUCTION	SOT23, Low-Power Microprocessor Supervisory Circuits with Battery Backup

MAX802L	PRODUCTION	Microprocessor Supervisory Circuits
MAX802M		Microprocessor Supervisory Circuits
MAX805L	PRODUCTION	Microprocessor Supervisory Circuits
