MAX40110

15MHz, Low-Noise, Precision Operational Amplifiers

Show More showmore-icon

Fast Auto-Calibration Provides Accuracy Over Time and Temperature

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 2
1ku List Price Starting From $0.44
Features
  • Fast Power-up Time of less than 1ms
  • Supply Voltage Range: 1.7V to 5.5V
  • Low 140µV (Max) Input Offset Voltage with Power-On Auto-Cal at +25°C
  • 15MHz GBW
  • Low 12.7nV/ Input Voltage-Noise Density
  • 750µA Quiescent Current
  • Rail-to-Rail Inputs and Outputs
  • Internal EMI Rejection
  • <1pA Low Input Bias Current
  • Power-Saving Shutdown Mode
  • Available in a Tiny 6-bump WLP and a Thin 6-µDFN Package
Additional Details
show more Icon

The MAX40110/MAX40111 offer a unique combination of high speed, precision, low noise, and low-voltage operation, making them ideally suited for a large number of signal processing functions including filtering and amplification of signals in portable and industrial equipment.

The MAX40110/MAX40111s' rail-to-rail input/outputs and low noise guarantee maximum dynamic range in demanding applications such as 12- to 14-bit SAR ADC drivers. Unlike traditional rail-to-rail input structures, input crossover distortion is absent due to an optimized input stage with an ultra-quiet charge pump. The input offset voltage is as low as 30µV due to the auto-calibration performed on power-up. The devices also include a fast-power-on shutdown mode for further power savings.

The MAX40110/MAX40111 operate from a supply range of 1.8V to 5.5V over the -40°C to +125°C extended operating temperature range and consume only 750μA (typ) supply current. The MAX40110 is offered in an ultra-thin 6-µDFN package, and the MAX40111 is available in a tiny 6-bump wafer-level-package (WLP) with a 0.4mm pitch.

The MAX40110/MAX40111 are an extension of the MAX44259/60/61/63 and MAX44290 families with a reduced power up time of less than 1ms.

Applications

  • Wearable Devices
  • Home Medical (Blood Glucose, Weight Scale, Blood Pressure, EKG)
  • Industrial IOT (Pressure, Flow, Level, Temperature, Proximity)
  • Optical Sensors
  • SAR ADC Driver
Part Models 2
1ku List Price Starting From $0.44

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX40110AYT+
  • HTML
  • HTML
MAX40110AYT+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 2

reference details image

MAX40111EVKIT

Evaluation Kit for the MAX40111

zoom

MAX40111EVKIT

Evaluation Kit for the MAX40111

Evaluation Kit for the MAX40111

Features and Benefits

  • Accommodates Multiple Op Amp Configurations
  • Component Pads Allow for Sallen-Key Filter
  • Accommodates Easy-to-Use Components
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX40111 evaluation kit (EV kit) provides a proven design to evaluate the MAX40111 low-offset, low-power, rail-to-rail I/O operational amplifier in a 6-pin wafer-level package (WLP). The EV kit circuit is preconfigured as noninverting amplifiers, but can be adapted to other topologies by changing a few components.

The EV kit comes with a MAX40111ANT+ installed.

Applications

  • Home Medical (Blood Glucose, Weight Scale, Blood Pressure, EKG)
  • Industrial IOT (Pressure, Flow, Level, Temperature, Proximity)
  • Optical Sensors
  • SAR ADC Driver
  • Wearable Devices
reference details image

MAX40110EVKIT

Evaluation Kit for the MAX40110

zoom

MAX40110EVKIT

Evaluation Kit for the MAX40110

Evaluation Kit for the MAX40110

Features and Benefits

  • Accommodates Multiple Op Amp Configurations
  • Component Pads Allow for Sallen-Key Filter
  • Accommodates Easy-to-Use Components
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX40110 evaluation kit (EV kit) provides a proven design to evaluate the MAX40110 low-noise, low-power, low-bias-current operational amplifier in a 6-pin µDFN package. The EV kit circuit is preconfigured as noninverting amplifiers, but can be adapted to other topologies by changing a few components.

The EV kit comes with a MAX40110AYT+ installed.

Applications

  • Home Medical (Blood Glucose, Weight Scale, Blood Pressure, EKG)
  • Industrial IOT (Pressure, Flow, Level, Temperature, Proximity)
  • Optical Sensors
  • SAR ADC Driver
  • Wearable Devices
