MAX25405
IR Gesture Sensor with Lens for Automotive Applications
Show More
Automotive Low-Cost IR-Based Gesture Sensor
Not the part you were looking for?
Ask a Question
Submit your question below and we will return the best answer from ADI’s knowledge database:
Search
Other places you can find help
Support
Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.
Visit the ADI Support Page
Features
- Low-Cost, Flexible Gesture-Sensing Solution for Automotive Applications
- Low-Power, Low-Cost External CPU Processes Sensor Output
- Supports Swipe, Rotation, and Proximity Gestures
- Highly Integrated
- Integrated Lens, Aperture, and Filter
- 60-Pixel IR Photodiode Array
- Integrated LED Driver
- 400kHz I2C and 6MHz SPI Serial Interfaces
- Operates in 120k Lux Ambient Light
- AEC-Q100 Qualified
- -40°C to +85°C Operation
- MSL1
- Ultra-Low-Power Operation
- 1mA at 3.3V
- Compact 4mm x 4mm x 1.35mm, 20-Pin, Side- Wettable QFN Package
