MAX17580
PRODUCTION4.5V to 60V, 300mA High-Efficiency, Synchronous, Inverting Output DC-DC Converters
Creates a Negative Output Voltage in a Small Solution Size, No External Level Shifters
- Part Models
- 2
- 1ku List Price
- Starting From $2.35
Overview
- Reduces External Components and Total Cost
- Synchronous Operation
- All-Ceramic Capacitors, Compact Layout
- Internal Loop Compensation
- System Ground Referenced I/O Pins (EN/UVLO, active-low RESET)
- Flexibility to Support Multiple Rails in a System
- Adjustable Output Voltage Range from -0.9V to -36V
- Wide 4.5V to (60V-|VOUT|) Input-Voltage Range
- Up to 300mA Output Current
- 400kHz to 2.2MHz Adjustable Frequency with External Clock Synchronization
- Reduces Power Dissipation
- 88.4% Peak Efficiency
- DCM for Superior Light-Load Efficiency
- 6.2μA Shutdown Current
- Operates Reliably in Adverse Industrial Environments
- Hiccup-Mode Overload Protection
- Adjustable Soft-Start
- Monotonic Startup with Prebiased Output Voltage
- Built-in Output Voltage Monitoring with Active-Low RESET
- Programmable EN/UVLO Threshold
- Overtemperature Protection
- Wide -40°C to +125°C Ambient Operating Temperature Range / -40°C to +150°C Junction Temperature Range
The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power-supply solutions. The MAX17579 and MAX17580 are high-efficiency, high-voltage, inverting, Himalaya synchronous DC-DC converters with integrated MOSFETs and internal compensation. The devices generate output voltages (VOUT) from -0.9V to -36V and can deliver up to 300mA of load current from a wide 4.5V to (60V-|VOUT|) input-voltage range.
The devices feature peak current-mode control architecture. The MAX17579 operates in continuous conduction mode (CCM) at all loads, thus, providing a constant frequency operation. The MAX17580 operates in discontinuous conduction mode (DCM) for superior efficiency at light loads. Low minimum on-time allows higher switching frequencies and small solution sizes.
The devices allow the EN/UVLO, active-low RESET and RT/SYNC pins to be driven by signals that are referenced to system ground, eliminating the need for external-level shifter circuits. The feedback-voltage regulation accuracy is ±1.3% over a wide -40°C to +125°C temperature range. The devices are available in a compact 12-pin (3mm x 3mm) TDFN-EP package. Simulation models are available.
Applications
- Industrial Control Power Supply
- General Purpose Point-of-Load
- Gate-Drive Circuits
- Motion Control
- Wall-Transformer Regulation
- High-Voltage, Single-Board System
Documentation
Data Sheet 1
Technical Articles 2
Video 1
Webcast 1
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.
| Part Model | Pin/Package Drawing | Documentation | CAD Symbols, Footprints, and 3D Models |
|---|---|---|---|
| MAX17580ATC+ | Thin Dual Flatpack No Leads | ||
| MAX17580ATC+T | Thin Dual Flatpack No Leads |
This is the most up-to-date revision of the Data Sheet.
