MAX17300

1-Cell ModelGauge m5 EZ Fuel Gauge with Protector, Internal Self-Discharge Detection and SHA-256 Authentication

Industry's Lowest I_Q Stand-Alone Fuel Gauge with Protector

RECOMMENDED FOR NEW DESIGNS

RECOMMENDED FOR NEW DESIGNS

MAX17301, MAX17302, MAX17303, MAX17311, MAX17312, MAX17313: Functional Diagram slide

MAX17300 Typical Application Circuits slide

MAX17300 Pin Configuration TDFN slide

MAX17300Pin Configuration WLP slide

MAX17301, MAX17302, MAX17303, MAX17311, MAX17312, MAX17313: Functional Diagram

MAX17300 Typical Application Circuits

MAX17300 Pin Configuration TDFN

MAX17300Pin Configuration WLP

Not the part you were looking for?

Go to Product Selection Table

View All Documentation

Ask a Question

Submit your question below and we will return the best answer from ADI’s knowledge database:

Search

Other places you can find help

Support

Analog Devices Support Portal is a one-stop shop to answer all your ADI questions.

Visit the ADI Support Page

EngineerZone Icon

Ask the ADI community for help.

Ask the EngineerZone Community

FAQs

Sales & Ordering FAQs

Part Models 4

1ku List Price Starting From $2.21

Features

Battery Health + Programmable Safety/Protection
- Overvoltage (Temperature Dependent)
- Overcharge Current
- Over/Undertemperature
- Battery Internal Self-Discharge Detection (MAX17300/10 Only)
- Ideal Diode Discharge During Charge Fault
- Charging Prescriptions (JEITA)
- Zero-Volt Charging Option
- Undervoltage + SmartEmpty
- Overdischarge/Short-Circuit
Nonvolatile Memory for Stand-Alone Operation
- History Logging, User Data (122 Bytes)
Low Quiescent Current
- FETs Enabled: 24µA Active, 18µA Hibernate
- FETs Disabled: 5µA Ship, 0.5µA/0.02µA DeepShip
Parallel Battery Management (MAX17300/10 Only)
Pushbutton Wakeup—Eliminates System Consumption Until Button Press
ModelGauge m5 EZ Algorithm
- Percent, Capacity,Time-to-Empty/Full, Age
- Cycle+™ Age Forecast
Dynamic Power—Estimates Power Capability
Precision Measurement Without Calibration
- Current, Voltage, Power, Time, Cycles
- Die Temperature/Thermistor

Additional Details

The MAX17300–MAX17303/MAX17310–MAX17313 is a 24μA I_Q stand-alone pack-side fuel gauge IC with protector and optional SHA-256 authentication for 1-cell lithium-ion/polymer batteries.

The IC monitors the voltage, current, temperature, and state of the battery to provide against over/undervoltage, overcurrent, short-circuit, over/undertemperature and overcharge conditions protection using external high-side N-FETs, and provides charging prescription to ensure that the lithium-ion/polymer battery operates under safe conditions prolonging the life of the battery.

To prevent battery pack cloning, the IC integrates SHA-256 authentication with a 160-bit secret key. Each IC incorporates a unique 64-bit ID.

The fuel gauge uses ModelGauge m5 algorithm that combines the short-term accuracy and linearity of a coulomb counter with the long-term stability of a voltage-based fuel gauge to provide industry-leading fuel-gauge accuracy.

The IC automatically compensates for cell aging, temperature, and discharge rate, and provides accurate state-of-charge (SOC) in milliampere-hours (mAh) or percentage (%) over a wide range of operating conditions.

Dynamic power functionality provides the instantaneous maximum battery output power which can be delivered to the system without violating the minimum system input voltage.

A Maxim 1-Wire^® or 2-wire I²C interface provides access to data and control registers. The IC is available in a lead-free, 3mm x 3mm 14-pin TDFN and 1.7mm x 2.5mm 15-bump 0.5mm pitch WLP packages.

Applications

Smartphones, Tablets, and 2-in-1 Laptops
Smartwatches and Wearables
Medical Devices, Health and Fitness Monitors
Digital Still, Video, and Action Cameras
Handheld Computers and Terminals
Handheld Radios
Home and Building Automation, Sensors
Smart Batteries
