HMC557A: GaAs, MMIC Fundamental Mixer, 2.5 GHz to 7.0 GHz Data Sheet (Rev. F)9/11/2015PDF328 K
Overview
Features and Benefits
- Conversion loss: 8 dB
- LO to RF isolation: 50 dB
- LO to IF isolation: 35 dB
- Input third-order intercept (IP3): 18 dBm
- Input second-order intercept (IP2): 55 dBm
- LO port return loss: 8 dBm
- RF port return loss: 10 dBm
- Passive double balanced topology
- Wide IF bandwidth: dc to 3 GHz
- 24-terminal ceramic leadless chip carrier package
Product Details
The HMC557A is a general-purpose, double balanced mixer in a 24-terminal, ceramic leadless chip carrier, RoHS-compliant package. The device can be used as an upconverter or downconverter from 2.5 GHz to 7.0 GHz. This mixer is fabricated in a gallium arsenide (GaAs) metal semiconductor field effect transistor (MESFET) process and requires no external components or matching circuitry.
The HMC557A provides excellent local oscillator (LO) to radio frequency (RF) and LO to intermediate frequency (IF) isolation due to optimized balun structures. The RoHS-compliant HMC557A eliminates the need for wire bonding and is compatible with high volume surface-mount manufacturing techniques.
Applications
- WiMAX and fixed wireless
- Point to point radios
- Point to multipoint radios
- Test equipment and sensors
- Military end use
Product Categories
Markets and Technologies
Product Lifecycle
Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
