Features and Benefits
- SSB Phase Noise:
-153 dBc/Hz @ 100 kHz
- Selectable Division from 2 to 32
- Parallel 5-Bit Control
- Wide Input Power Range:
-20 to +10 dBm
- 4x4 mm Leadless SMT Package
The HMC394LP4(E) is a low noise GaAs HBT programmable 5-bit counter in 4x4 mm leadless surface mount package. This device allows continuous division from N= 2 to 32 at input frequencies up to 2.2 GHz. The output voltage swing is 800 mV with a duty cycle inversely proportional to N. The low additive SSB phase noise of -153 dBc/Hz at 100 KHz offset makes this counter an excellent choice for low noise synthesizer applications.
- Satellite Communication Systems
- Point-to-Multi-Point Radios
