  5. HMC344A

View All Data Sheets (3)
Data Sheet Rev. A
S-Parameters
1 View All

Alternative Parts

ADRF5040
ADRF5040

Functional alternative in Silicon (SOI)

Overview

Features and Benefits

  • Broadband frequency range: 0.1 GHz to 8 GHz
  • Nonreflective 50 Ω design
  • Low insertion loss: 1.7 dB at 6 GHz
  • High isolation: 36 dB at 6 GHz
  • High input linearity at 250 MHz to 8 GHz
    • P1dB: 28 dBm typical
    • IP3: 44 dBm typical
  • Integrated 2 to 4 line decoder
  • 16-lead, 3 mm × 3 mm LFCSP package
  • ESD HBM rating: 250 V (Class 1A)
HMC344A supports defense and aerospace applications (AQEC standard)
  • Download the HMC344ATCPZ-EP data sheet
  • Military temperature range (−55°C to +125°C)
  • Controlled manufacturing baseline
  • One assembly/test site
  • Product change notification
  • Qualification data available on request

Product Details

The HMC344ALP3E is a broadband, nonreflective, single-pole, four-throw (SP4T) switch manufactured using a gallium arsenide (GaAs) metal semiconductor field effect transistor (MESFET) process. This switch offers high isolation, low insertion loss, and on-chip termination of the isolated ports.

The switch operates with a negative supply voltage (VEE) range of −5 V to −3 V and requires two negative logic control voltages.

The HMC344ALP3E includes an on-chip, binary two-line to four-line decoder that provides logic control from two logic input lines.

The HMC344ALP3E comes in a 3 mm × 3 mm, 16-lead LFCSP package and operates from a 0.1 GHz to 8 GHz frequency range.

Applications

  • Broadband telecommunications systems
  • Fiber optics
  • Switched filter banks
  • Wireless Infrastructure below 8 GHz

Product Categories

Comparable Parts Click to see all in Parametric Search

Product Lifecycle icon-recommended Recommended for New Designs

This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
