ADUM1100

iCoupler Digital Isolator

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.K)
Documentation View All Documentation
IBIS Model ADuM1100 IBIS Model (All Speed Grades) Download B
Part Models 6
1ku List Price Starting From $1.66
Features
  • High data rate: dc to 100 Mbps (NRZ)
  • Compatible with 3.3 V and 5.0 V operation/level translation
  • 125°C maximum operating temperature
Low Power Operation
  • 5 V operation
    1.0 mA maximum @ 1 Mbps
    4.5 mA maximum @ 25 Mbps
    16.8 mA maximum @ 100 Mbps
  • 3.3 V operation
    0.4 mA maximum @ 1 Mbps
    3.5 mA maximum @ 25 Mbps
    7.1 mA maximum @ 50 Mbps
  • 8-lead SOIC_N package (RoHS compliant version available)
  • High common-mode transient immunity: >25 kV/μs
Safety and Regulatory Information
  • UL recognized
  • 2500 V rms for 1 minute per UL 1577
  • CSA Component Acceptance Notice 5A
  • VDE Certificate of Conformity
    DIN V VDE V 0884-10
    (VDE V 0884-10):2006-12
    VIORM = 560 V peak
Additional Details
show more Icon

The ADuM1100 is a digital isolator based on Analog Devices Inc., iCoupler® technology. Combining high speed CMOS and monolithic air core transformer technology, this isolation component provides outstanding performance characteristics superior to alternatives, such as optocoupler devices.

Configured as a pin-compatible replacement for existing high speed optocouplers, the ADuM1100 supports data rates as high as 25 Mbps and 100 Mbps.

The ADuM1100 operates with a voltage supply ranging from 3.0 V to 5.5 V, boasts a propagation delay of <18 ns and edge asymmetry of <2 ns, and is compatible with temperatures up to 125°C. It operates at very low power, less than 0.9 mA of quiescent current (sum of both sides), and a dynamic current of less than 160 μA per Mbps of data rate. Unlike other optocoupler alternatives, the ADuM1100 provides dc correctness with a patented refresh feature that continuously updates the output signal.

The ADuM1100 is offered in three grades. The ADuM1100AR and ADuM1100BR can operate up to a maximum temperature of 105°C and support data rates up to 25 Mbps and 100 Mbps, respectively. The ADuM1100UR can operate up to a maximum temperature of 125°C and supports data rates up to 100 Mbps.

APPLICATIONS

  • Digital field bus isolation
  • Opto-isolator replacement
  • Computer-peripheral interface
  • Microprocessor system interface
  • General instrumentation and data acquisition applications
Show More Arrow image
file View Data Sheet (Rev.K)
Documentation View All Documentation
IBIS Model ADuM1100 IBIS Model (All Speed Grades) Download B
Part Models 6
1ku List Price Starting From $1.66
