ADRF6780S

The ADRF6780S is a silicon germanium (SiGe) design, wideband, microwave upconverter optimized for point to point microwave radio designs operating in the 5.9 GHz to 23.6 GHz frequency range.

The upconverter offers two modes of frequency translation. The device is capable of direct conversion to RF from baseband in-phase quadrature (I/Q) input signals, as well as single sideband (SSB) upconversion from a real intermediate frequency (IF) input carrier frequency. The baseband inputs are high impedance and are generally terminated off chip with 100 Ω differential back terminations. The baseband I/Q input path can be disabled and a modulated real IF signal anywhere from 0.8 GHz to 3.5 GHz can fed into the IF input path and upconverted to 5.9 GHz to 23.6 GHz while suppressing the unwanted sideband by typically better than 25 dBc. The serial port interface (SPI) allows tweaking of the quadrature phase adjustment to allow optimum sideband suppression. In addition, the SPI allows powering down the output power detector to reduce power consumption when power monitoring is not necessary.

The ADRF6780S upconverter comes in a compact, thermally enhanced, 5 mm × 5 mm LFCSP. The ADRF6780S operates over the −40°C to +85°C temperature range.

Additional application and technical information can be found in the Commercial Space Products Program brochure and ADRF6780 data sheet.
