Overview

Features and Benefits

  • Wideband switch: −3 dB at 4 GHz
  • Absorptive/reflective switches
  • High off isolation (43 dB at 1 GHz)
  • Low insertion loss (0.8 dB at 1 GHz)
  • Single 1.65 V to 2.75 V power supply
  • CMOS/LVTTL control logic
  • 8-lead MSOP and tiny 3 mm × 3 mm LFCSP
  • Low power consumption (<1 µA)

Product Details

The ADG918/ADG919 are wideband switches using a CMOS process to provide high isolation and low insertion loss to 1 GHz. The ADG918 is an absorptive (matched) switch having 50 Ω terminated shunt legs, whereas the ADG919 is a reflective switch. These devices are designed such that the isolation is high over the dc to 1 GHz frequency range. They have on-board CMOS control logic, thus eliminating the need for external controlling circuitry. The control inputs are both CMOS and LVTTL compatible. The low power consumption of these CMOS devices makes them ideally suited to wireless and general-purpose high frequency switching applications.

Product Highlights

  1. −43 dB off isolation at 1 GHz.
  2. 0.8 dB insertion loss at 1 GHz.
  3. Tiny 8-lead MSOP/LFCSP.

Applications

  • Wireless communications
  • General-purpose RF switching
  • Dual-band applications
  • High speed filter selection
  • Digital transceiver front end switch
  • IF switching
  • Tuner modules
    Antenna diversity switching

Product Categories

Comparable Parts Click to see all in Parametric Search

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.

Evaluation Kits (1)

Documentation & Resources

  • View All (10)
  • Data Sheets (1)
  • Application Notes (1)
  • User Guides (1)
  • Product Selection Guide (3)
  • Circuit Note (1)
  • Videos (1)
  • Technical Articles (2)
    • Document Type

    Tools & Simulations

    LTspice

    LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.

    LTspice

    Models for the following parts are available in LTspice:

    ADG918

    S-Parameters

    Design Resources

    ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well.  "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.

    Part Number Material Declaration Reliability Data Pin/Package Drawing CAD Symbols, Footprints & 3D Models
    ADG918BCPZ-500RL7 Material Declaration Reliability Data 8-Lead LFCSP (3mm x 3mm w/ EP)
    ADG918BCPZ-REEL7 Material Declaration Reliability Data 8-Lead LFCSP (3mm x 3mm w/ EP)
    ADG918BRMZ Material Declaration Reliability Data 8-Lead MSOP
    ADG918BRMZ-500RL7 Material Declaration Reliability Data 8-Lead MSOP
    ADG918BRMZ-REEL Material Declaration Reliability Data 8-Lead MSOP
    ADG918BRMZ-REEL7 Material Declaration Reliability Data 8-Lead MSOP
