Features and Benefits
- RF frequency range: 169.4 MHz to 169.6 MHz
- Modulation: 2GFSK, 4GFSK
- Data rates:
2GFSK: 2.4 kbps and 4.8 kbps
4GFSK: 6.4 kbps (Tx only)
- 1nA sleep current
- Receiver performance
97 dB blocking at ±10 MHz offset
66 dB adjacent channel rejection
−122 dBm sensitivity
- See data sheet for additional features
The ADF7030 is a low power, high performance, integrated radio transceiver supporting narrowband operation in the 169.4MHz to 169.6MHz ISM bands. The ADF7030 supports transmit and receive operation at 2.4kbps and 4.8kbps using 2GFSK modulation and transmit operation at 6.4kbps using 4GFSK modulation.
The ADF7030 features an on-chip ARM® Cortex®-M0 processor that performs radio control and packet management.Applications
- Wireless M-Bus Mode N (EN 13757-4)
- Smart metering
- Social alarms
- Active tag asset tracking
Markets and Technologies
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The ADF7030 daughter board (EVAL-ADF7030DB7Z) is intended for use with the EVAL-ADF7XXXMB4Z mother board, which needs to be ordered separately. The ADF7030 layout uses a separate matching circuit for the single ended PA and differential LNA. The layout uses a 4-layer board stack-up and 0402 passives.
