Features
- 400 MSPS Internal DDS Clock Speed
- 48-bit frequency tuning word
- 14-bit Programmable Phase Offset
- Integrated 14-bit DAC
- Excellent Dynamic Performance
- Phase noise ≤ 135 dBc/Hz @ 1 KHz offset
- −80 dB SFDR @ 160 MHz (±100 KHz offset IOUT)
- 25 Mb/s write-speed serial I/O control
- 655 MHz programmable input dividers for the phase
- frequency detector (÷M, ÷N) {M, N = 1..16} (bypassable)
- Programmable RF divider (÷R) {R = 1, 2, 4, 8} (bypassable)
- 8 phase/frequency profiles
- 1.8 V supply for device operation
- 3.3 V supply for I/O and charge pump
- Software controlled power-down
- 48-lead LFCSP package
- Automatic linear frequency sweeping capability (in DDS)
- Programmable charge pump current (up to 4 mA)
- Phase modulation capability
- Multichip synchronization
- Dual-mode PLL lock detect
- 655 MHz CML-mode PECL-compliant driver
.svg?rev=fd385c90e2cf4716ae9a8c8d20e6b8e3&la=en&h=24&w=24&hash=A302DF48F94BAAA11877AF223F27157A){kind=icon}
The AD9956 is specified to operate over the extended automotive range of −40°C to +125°C.
Applications
- Agile LO frequency synthesis
- FM chirp source for radar and scanning systems
- Automotive radars
- Test and measurement equipment
- Acousto-optic device drivers
