Overview
Features and Benefits
- High common-mode voltage range
- −2 V to +65 V operating
- Buffered output voltage
- 5 mA output drive capability
- Wide operating temperature range: −55°C to +125°C
- Ratiometric half-scale output offset
- Excellent ac and dc performance
- 1 μV/°C typical offset drift
- 10 ppm/°C typical gain drift
- 120 dB typical CMRR at dc
- 80 dB typical CMRR at 100 kHz
Product Details
The AD8210S is a single-supply, difference amplifier ideal for amplifying small differential voltages in the presence of large common-mode voltages. The operating input common-mode voltage range extends from −2 V to +65 V. The typical supply voltage is 5 V.
Excellent ac and dc performance over temperature keep errors in the measurement loop to a minimum. Offset drift and gain drift are guaranteed to a maximum of 8 μV/°C and 20 ppm/°C, respectively.
Product Categories
Markets & Technology
Product Lifecycle
Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
