Features and Benefits
- Low power replacement for Burr-Brown
- OPA111, OPA121 op amps
- Low noise
- 3.3 μV P-P maximum, 0.1 Hz to 10 Hz
- 11 nV/√Hz maximum at 10 kHz
- 0.6 fA/√Hz at 1 kHz
- High dc accuracy
- 500 μV maximum offset voltage
- 10 μV/°C maximum drift
- 2 pA maximum input bias current
- Low power: 1.5 mA maximum supply current
The AD795 is a low noise, precision, FET input operational amplifier. It offers both the low voltage noise and low offset drift of a bipolar input op amp and the very low bias current of a FET-input device. The 1014 Ω common-mode impedance insures that input bias current is essentially independent of common-mode voltage and supply voltage variations.
The AD795 has both excellent dc performance and a guaranteed and tested maximum input voltage noise. It features 2 pA maximum input bias current and 500 μV maximum offset voltage, along with low supply current of 1.5 mA maximum.
Furthermore, the AD795 features a guaranteed low input noise of 3.3 μV P-P (0.1 Hz to 10 Hz) and a 11 nV/√Hz maximum noise level at 10 kHz. The AD795 has a fully specified and tested input offset voltage drift of only 10 μV/°C maximum.
The AD795 is useful for many high input impedance, low noise applications. The AD795 is rated over the commercial temperature range of 0°C to +70°C.
The AD795 is available in an 8-lead SOIC package.
- Low noise photodiode preamps
- CT scanners
- Precision l-to-V converters
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (1)
The Universal Precision Op Amp Evaluation Boards have been designed and optimized for many circuit configurations allowing the users to best suit their applications. These boards are all RoHs Compliant. See references below on what board to order by lead count and package.
- EVAL-PRAOPAMP-1KSZ (Single 5-Lead SC70) KS-5
- EVAL-PRAOPAMP-1RJZ (Single 5-Lead SOT 23) RJ-5
- EVAL-PRAOPAMP-1RMZ (Single 8-Lead MSOP) RM-8
- EVAL-PRAOPAMP-1RZ (Single 8-Lead SOIC) R-8
Application Notes (6)
Tools & Simulations
LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.
Models for the following parts are available in LTspice:
AD795 SPICE Macro Models
Use the Analog Filter Wizard to design low-pass, high-pass, or band-pass filters with actual op amps in minutes. As you progress through the design process, you can observe the characteristics of your filter design from ideal specifications to real world circuit behavior. Quickly evaluate the tradeoffs in op amp specifications - including gain-bandwidth, noise, and supply current – to determine the best filter design for your requirements.
Use Photodiode Wizard to design a transimpedance amplifier circuit to interface with a photodiode. Select a photodiode from the library included in the tool, or enter custom photodiode specifications. Quickly observe tradeoffs between Bandwidth, Peaking (Q), and ENOB/SNR. Modify circuit parameters, and immediately see results in plots for pulse response, frequency response, and noise gain.
