AD7607
8-Channel DAS with 14-Bit, Bipolar, Simultaneous Sampling ADC
Top
Overview
Features and Benefits
- 8 simultaneously sampled inputs
- True bipolar analog input ranges: ±10 V, ±5 V
- Single 5 V analog supply and 2.3 V to 5.25 V VDRIVE
- Fully integrated data acquisition solution
- Analog input clamp protection
- Input buffer with 1 MΩ analog input impedance
- Second-order antialiasing analog filter
- On-chip accurate reference and reference buffer
- 14-bit ADC with 200 kSPS on all channels
- Flexible parallel/serial interface
- SPI/QSPI™/MICROWIRE™/DSP compatible
- Pin-compatible solutions from 14 bits to 18 bits
- Performance
- 7 kV ESD rating on analog input channels
- Fast throughput rate: 200 kSPS for all channels
- 85.5 dB SNR at 50 kSPS
- INL ±0.25 LSB, DNL ±0.25 LSB
- Low power: 100 mW at 200 kSPS
- Standby mode: 25 mW typical
- 64-lead LQFP package
Product Details
The AD7607 is a 14-bit, simultaneous sampling, analog-to-digital data acquisition system (DAS). The part contains analog input clamp protection; a second-order antialiasing filter; a track-and-hold amplifier; a 14-bit charge redistribution, successive approximation analog-to-digital converter (ADC); a flexible digital filter; a 2.5 V reference and reference buffer; and high speed serial and parallel interfaces.
The AD7607 operates from a single 5 V supply and can accommodate ±10 V and ±5 V true bipolar input signals while sampling at throughput rates of up to 200 kSPS for all channels. The input clamp protection circuitry can tolerate voltages of up to ±16.5 V. The AD7607 has 1 MΩ analog input impedance, regardless of sampling frequency. The single supply operation, on-chip filtering, and high input impedance eliminate the need for driver op amps and external bipolar supplies. The AD7607 antialiasing filter has a 3 dB cutoff frequency of 22 kHz and provides 40 dB antialias rejection when sampling at 200 kSPS. The flexible digital filter is pin driven and can be used to simplify external filtering.
Applications
- Power-line monitoring and protection systems
- Multiphase motor control
- Instrumentation and control systems
- Multiaxis positioning systems
- Data acquisition systems (DAS)
Product Categories
Markets and Technologies
Product Lifecycle
Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
Documentation & Resources
-
AD7606x Family1/25/2021
Reference Designs (1)
Product Recommendations
AD7607 Companion Parts
Recommended Digital Isolators
- For high performance, low power, bidirectional communication with integrated isolated power: ADUM5402.
- For high performance, low power, bidirectional communication: ADUM1402.
- For isolated power in 3.3V or 5V outputs: ADUM5000.
Recommended External 2.5V Voltage Reference
