HMC220A

Obsolete

DBL-BAL Mixer SMT, 5 - 12 GHz

Part Models: 4
1ku List Price: price unavailable

Viewing:

Overview

Ultra Small Package: MSOP8
Conversion Loss: 8.5 dB
Wideband IF: DC - 4 GHz

The HMC220AMS8E is an ultra miniature double-balanced mixer in an 8 lead plastic surface mount package (MSOP). This passive MMIC mixer is constructed of GaAs Schottky diodes and novel planar transformer baluns on the chip. The device can be used as an upconverter, downconverter, bi-phase (de)modulator, or phase comparator. The consistent MMIC performance will improve system operation and assure regulatory compliance.

Applications

Microwave Radios
VSAT

Part Models: 4
1ku List Price: price unavailable

Documentation

Obsolete Data Sheet 1

HMC220AMS8/HMC220AMS8E: GaAs MMIC SMT Double-Balanced Mixer, 5 - 12 GHz Obsolete Data Sheet 02/05/2015

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
HMC220AMS8	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
HMC220AMS8E	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
HMC220AMS8ETR	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
HMC220AMS8TR	8-Lead MSOP	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jan 11, 2017 - 16_0010 Discontinuance of Select RF and Microwave Products
		PDN16_0010_Form Material_Report
HMC220AMS8	Obsolete
HMC220AMS8E
HMC220AMS8ETR
HMC220AMS8TR	Obsolete
