REF10S

量产

Aerospace +10V Precision Voltage Reference

数据手册 产品选型表
产品技术资料帮助

ADI公司所提供的资料均视为准确、可靠。但本公司不为用户在应用过程中侵犯任何专利权或第三方权利承担任何责任。技术指标的修改不再另行通知。本公司既没有含蓄的允许，也不允许借用ADI公司的专利或专利权的名义。本文出现的商标和注册商标所有权分别属于相应的公司。
Viewing:

概述

  • 10 Volt Output
  • Guaranteed Long-Term Stability:
    50ppm/1000 Hrs Max
  • Excellent Temperature Stability:
    8.5ppm/°C Max
  • Low Noise: 30µVp-p Max
  • Low Supply Current: 1.4mA Max
  • Wide Input Voltage Range: 12V to 40V
  • High Load-Driving Capability: 20mA
  • High Load-Driving Capability: 20mA

The REF10 precision voltage reference provides a stable +10V output which can be adjusted over a ±3% range with minimal effect on temperature stability. Long-term drift is guaranteed at 50ppm/1000 hours maximum. Single-supply operation over an input voltage range of 12V to 40V, low current drain of 1mA, and excellent temperature stability are achieved with an improved bandgap design. Low noise and low power make the REF10 an excellent choice whenever a stable voltage reference is required. Applications include D/A and A/D converters, portable instrumentation, and digital voltmeters.

REF10S
Aerospace +10V Precision Voltage Reference
