MAX14982

All-In-One Ruggedized 5GT/s 2:1/1:2 PCIe Mux and Redriver with Equalization

Viewing:

概述

Fully Integrated for Ease of Use and Design Flexibility
- Capable of Switching Between Multiple Hosts and Sinks While Overcoming Board Losses
- Optimized for PCIe Gen II (5.0GT/s); Gen I (2.5GT/s) Compatible
- Three Levels of Independent Programmable Input Equalization and Output Deemphasis Up to 6dB
High Level of Performance to Overcome Noise in Lossy Channels
- Random Jitter: 0.5ps_RMS (typ)
- Deterministic Jitter: 20ps_P-P (typ)
- Equalization Permits Placement Up to 30in FR4
Robust Solution for Harsh Environments
- Industrial Temperature Rated: -40°C to +85°C
- ±2.5kV Human Body Model (HBM) Protection on All Pins
- Housed in a Flow-Through (3.5mm x 9.5mm) TQFN Package for Resistance to Vibrations/Shocks
