DS2250

柔性微控制器模块

数据手册 (Rev. 2)

Viewing:

产品详情

8-bit 8051-Compatible Microcontroller Adapts to Task-At-Hand:
- 8, 32, or 64kB of NV RAM for Program and/or Data Memory Storage
- Initial Downloading of Software in End System via On-Chip Serial Port
- Capable of Modifying its own Program and/or Data Memory in End Use
High-Reliability Operation:
- Maintains all Nonvolatile Resources for 10 Years in the Absence of V_CC
- Power-Fail Reset
- Early Warning Power-Fail Interrupt
- Watchdog Timer
Software Security Feature:
- Executes Encrypted Software to Prevent Unauthorized Disclosure
On-Chip, Full-Duplex Serial I/O Ports
Two On-Chip Timer/Event Counters
32 Parallel I/O Lines
Compatible with Industry Standard 8051 Instruction Set
Permanently Powered Real-Time Clock
