機能と利点Absolute Maximum Ratings
- Supply Voltage: ±22V
- Internal Power Dissipation: 500mW
- Input Voltage: Equal to Supply Voltage
- Output Short-Circuit Duration: Indefinite
- Differential Input Voltage (Note 8): ±25mA
- Operating Temperature Range: –55°C to 125°C
- Junction Temperature Range: –55°C to 150°C
- Storage Temperature Range: –65°C to 150°C
- Lead Temperature (Soldering, 10 sec): 300°C
The RH37C combines very low noise with excellent precision and high speed specifications. The low 1/f noise corner frequency of 2.7Hz combined with 3.5nV√Hz 10Hz noise and low offset voltage make the RH37C an excellent choice for low frequency military instrumentation applications. The wafer lots are processed to our in-house Class S flow to yield circuits usable in stringent military applications.
For complete electrical specifications and performance curves see the OP-27/OP-37 data sheet.
