HMC9060

製造中止

12.5 GHz to 16.5 GHz GaAs MMIC I/Q Upconverter

Viewing:

製品情報

Conversion gain: 15 dB typical
Sideband rejection: 25 dB typical
Input power for 1 dB compression (P1dB): 8.5 dBm typical
Output third-order intercept (OIP3): 32 dBm typical
LO leakage at the RF output: 2 dBm typical
LO leakage at the IF input: -18 dBm typical
RF return loss: 13 dB typical
LO return loss: 8 dB typical
32-lead, 5mm × 5mm LFCSP package

The HMC9060 is a compact, gallium arsenide (GaAs), pseudomorphic high electron mobility transistors (pHEMT), monolithic microwave integrated circuit (MMIC) upconverter in a RoHS compliant low stress injection molded plastic LFCSP package that operates from 12.5 GHz to 16.5 GHz. This device provides a small signal conversion gain of 15 dB with 25 dBc of sideband rejection. The HMC9060 uses a radio frequency (RF) amplifier preceded by an in-phase/quadrature (I/Q) mixer, where the local oscillator (LO) is driven by a driver amplifier. IF1 and IF2 mixer inputs are provided, and an external 90° hybrid is needed to select the required sideband. The I/Q mixer topology reduces the need for filtering of the unwanted sideband. The HMC9060 is a much smaller alternative to hybrid style single-sideband (SSB) upconverter assemblies, and it eliminates the need for wire bonding by allowing the use of surface-mount manufacturing techniques.
