Switching Matrix Solutions

Switch matrix systems are typically used in medium- to high-density switching of multiple channels where any row can be connected to any column, making them ideal for routing multiple signals between instruments and the device under test.

Show More Arrow image


Value and Benefits

Analog Devices’ switch technology offers both solid state and MEMS solutions, enabling DC to RF switching in standard surface mount space saving packages. Our portfolio features advanced design techniques, robust silicon processes, innovative packaging, and comprehensive qualification and test.

This capability enables us to develop products that must have high performance, high reliability, a small footprint, and low power in high-density switching applications.

thumbsupImg Benefits

Features advanced design techniques and innovative packaging

thumbsupImg Benefits

Enables small footprint with high reliability

thumbsupImg Benefits

Offers comprehensive qualification and testing

carousel title icon

Solution Resources

Hardware Products
