MAX9648
General-Purpose, Low-Voltage, Single Comparators in Tiny Packages
Pin-for-Pin Compatible Replacements for LMX331/LMX331H
Top
Overview
Features and Benefits
- Guaranteed +1.8V to +5.5V Performance
- -40°C to +125°C Automotive Temperature Range
- Low Supply Current (60µA/Channel at VDD = +5.0V)
- Input Common-Mode Voltage Range Includes Ground
- No Phase Reversal for Overdriven Inputs
- Low Output Saturation Voltage (120mV)
- Internal 2mV Hysteresis (MAX9648)
- 5-Pin SC70 Space-Saving Package (2.0mm x 2.1mm x 1.0mm)
Product Details
The MAX9647/MAX9648 comparators are drop-in, pin-for-pin compatible replacements for the LMX331/LMX331H. The MAX9648 has the added benefit of internal hysteresis to provide noise immunity, preventing output oscillations even with slow moving input signals.
Advantage of the ICs include low supply voltage, small package, and low cost. They also offer a wide supply voltage range, wide operating temperature range, competitive CMRR and PSRR, response time characteristics, input offset, low noise, output saturation voltage, input bias current and RF immunity.
The ICs are available in both 5-pin SC70 and SOT23 packages.
Applications
- Battery-Powered Electronics
- General-Purpose Low-Voltage Applications
- General-Purpose Portable Devices
- Mobile Communications
- Notebooks and PDAs
Product Categories
Product Lifecycle
Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
