Features and Benefits
- 4x Buck-Boost Regulators, 1x Inductor
- 2.5V to 5.5V Input Voltage Range
- 0.5V to 4.0V Output Voltage Range
- 700mA Total Output Current (3.7VIN, 1.8VOUT)
- Single-Inductor Multiple-Outputs (SIMO)
- Up to 90% Efficiency
- 6.9µA Typical IQ with Two Outputs Enabled in Low-Power Mode
- I2C Interface and Dedicated Enable Pin
- Flexible Power Sequencer (FPS)
- 1.99mm x 1.99mm, 16-Bumps, 0.5mm Pitch Wafer-Level Package (WLP)
- < 40mm2 Solution Size
The MAX77655 is a highly efficient, complete power supply for low-power, ultra-compact applications. It provides four programmable buck-boost switching regulator outputs using only one inductor. Operating from a single Li-ion battery, the MAX77655 delivers a total of 700mA output current (3.7VIN, 1.8VOUT) in less than 40mm2 solution size.
An integrated sequencer controls full startup while an I2C interface allows the MAX77655 to be dynamically configured and monitored.
This device is part of the single-inductor multiple-output (SIMO) product family.
- TWS Bluetooth™ Headphones/Hearables
- Fitness, Health, Activity Monitors, and Smart Watches
- Portable Devices
- Sensors Nodes and Consumer Internet of Things (IoT)
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The MAX77655 evaluation kit (EV kit) allows for easy experimentation with the MAX77655 CCM single-inductor, multiple-output (SIMO) regulator and I2C interface
The Windows® -based software provides a user-friendly graphical interface as well as a detailed register-based interface to exercise the features of the MAX77655.
Features & Benefits
- Easy to Use
- GUI-Driven I2C Interface
- Assembled and Fully Tested
- On-Board Electronic Loads
- Electronic Loads with Steady-State, Transient, and Random Modes
- On-Board ADC
- Evaluation of Multiple On-Key Options
- Wide Inductor Pads for Wide Range of Case Codes
Documentation & Resources
UG-7278: MAX77655 Programmer's Guide9/15/2020170K
