MAX629

28V, Low-Power, High-Voltage, Boost or Inverting DC-DC Converter

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.2)
Documentation View All Documentation
Part Models 2
1ku List Price Starting From $4.58
Features
  • Internal, 500mA, 28V N-Channel Switch (No External FET Required)
  • Generates Positive or Negative Output Voltages
  • 80µA Supply Current
  • 1µA Max Shutdown Current
  • Up to 300kHz Switching Frequency
  • Adjustable Current Limit Allows Use of Small, Inexpensive Inductors
  • 8-Pin SO Package
Additional Details
show more Icon

The MAX629 low-power DC-DC converter features an internal N-channel MOSFET switch and programmable current limiting. It is designed to supply positive or negative bias voltages up to ±28V from input voltages in the 0.8V to VOUT range, and can be configured for boost, flyback, and SEPIC topologies.

The MAX629's current-limited pulse-frequency-modulation (PFM) control scheme provides high efficiency over a wide range of load conditions. An internal, 0.5A N-channel MOSFET switch reduces the total part count, and a high switching frequency (up to 300kHz) allows for tiny surface-mount magnetics.

The MAX629's combination of low supply current, logic-controlled shutdown, small package, and tiny external components makes it an extremely compact and efficient high-voltage biasing solution that's ideal for battery-powered applications. The MAX629 is available in an 8-pin SO package.

Applications

  • 2-Cell and 3-Cell Battery-Powered Applications
  • High-Efficiency DC-DC Boost Converters
  • Palmtop Computers
  • Positive or Negative LCD Bias Generators
  • Varactor Tuning Diode Bias
