Features and Benefits
- SmartWiper Control Provides Accelerated Wiper Motion
- Debounced Pushbutton Interface with Internal Pullup Resistors
- Logarithmic Taper with 2dB Steps Between Taps
- Single +2.7V to +5.5V or Dual ±2.7V Supply Operation
- Low 0.5µA Standby Supply Current
- Clickless Switching
- 10kΩ End-to-End Fixed Resistance Value
- Mute Function to -90dB (typ)
- Power-On Reset to -12dB Wiper Position
- 32 Tap Positions for Each Wiper
- Small 16-Pin QSOP Package
- Fading and Balancing Stereo Signals
- Stereo Blending and Mixing
- Stereo Volume Control
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Documentation & Resources
Reduce the Chances of Human Error: Part 2, Super Amps and Filters for Analog Interface3/8/2011
Improve Stereo Performance with Active Biasing4/6/2009
DACs vs. Digital Potentiometers: Which Is Right for My Application?4/11/2007
Audio Fading Circuit Using the MAX5456/MAX54575/23/2005
Audio Gain Control Using Digital Potentiometers12/26/2002
MAX5456 Companion Parts
Recommended Related Parts
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.View our quality and reliability program and certifications for more information.
|Part Number||Material Declaration||Reliability Data||Pin/Package Drawing||CAD Symbols, Footprints & 3D Models|
|MAX5456EEE+||Material Declaration||Reliability Data||16-QSOP-150_MIL|
|MAX5456EEE+T||Material Declaration||Reliability Data||16-QSOP-150_MIL|
|Wafer Fabrication Data|
