MAX38914

RECOMMENDED FOR NEW DESIGNS

4μVRMS Ultra-Low-Noise 1A LDO with Two-Level Output Voltage Selection

4µVRMS Ultra-Low-Noise 1A LDO

Data Sheet (Rev. 3) Product Selection Table
Viewing:

Overview

  • Delivers Flexible Output Range
    • 1.8V to 5.5V Input Voltage Range
    • 0.6V to 5.0V Output Voltage Range
    • 1A Maximum Output Current
    • 28mV Dropout at 1A Load Current and 5.0V Supply
    • 33mV Dropout at 1A Load Current and 3.6V Supply
  • Excellent DC and AC Performance
    • 1% Regulation over Line, Load, and Temperature
    • 4µVRMS of Output Noise, 10Hz to 100kHz
    • 75dB PSRR at 10kHz
  • High-Level System Integration
    • Integrated Pass-Through Function
    • Fast Active Discharge of 6Ω at OUT
    • Dynamic Two-Level Voltage Scaling with 33 Levels for Each Option for Flexible Configuration (MAX38913)
    • 2V, 2.3V Pre-Programmed Voltage Levels (MAX38914)
    • Stable with 4µF (Minimum Capacitance)
    • Overcurrent and Overtemperature Protection
    • Power-OK/Power-on-Reset Output
  • Operation Temperature Range from -40°C to +125°C
  • Package
    • 12-Bump, 0.4mm-Pitch WLP
    • 14-Pin, 3mm x 3mm TDFN

The MAX38913/MAX38914 is a low-noise linear regulator that delivers up to 1A of load current with as low as 4μVRMS of output noise. The MAX38913/MAX38914 can dynamically change its output voltage between two separate levels. The MAX38913/MAX38914 has the pass-through mode which, when enabled, completely bypasses the linear regulator.

This regulator maintains ±1% output accuracy over a wide input voltage range, temperature, and load conditions. The no-load quiescent current in the regulation mode is 1.37mA. During the pass-through mode, unlike the conventional dropout mode of an LDO, the MAX38913/MAX38914 consumes very little quiescent current. The MAX38913/MAX38914 has a 6Ω active discharge feature to quickly discharge output capacitors of up to 300μF.

The MAX38913 has 33 programmable output-voltage settings for both voltage selections. The MAX38914 has pre-programmed output voltage levels of 2.3V and 2V. The MAX38913/MAX38914 is packaged in either a space-saving 12-bump WLP or a full-featured 3mm x 3mm, 14-pin TDFN package. Optional power-OK and power-on-reset pins are available in the 14-pin TDFN version.

Applications

  • Image Sensors
  • Portable Sensor Applications
  • SD Memory Cards
MAX38914
4μVRMS Ultra-Low-Noise 1A LDO with Two-Level Output Voltage Selection
MAX38913 Typical Application Circuits MAX38913 Simplified Block Diagram MAX38913 14 TDFN Pin Configuration MAX38913 12 WLP Pin Configuration
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

Learn More
Add to myAnalog

Add media to the Resources section of myAnalog, to an existing project or to a new project.

Create New Project

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Hardware Ecosystem

Parts Product Life Cycle Description
MAX38913
RECOMMENDED FOR NEW DESIGNS 4µVRMS Ultra-Low-Noise 1A LDO with Two-Level Output-Voltage Selection
Modal heading
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project

Evaluation Kits

eval board
schematic 1
schematic 2
schematic 3
MAX38913AEVK

Evaluation Kit for the MAX38913 and MAX38914

Buy Now View Details

Features and Benefits

  • Evaluates the MAX38913A IC in a 12-Pin (3x4 0.4mm Pitch) WLP
  • 1.8V to 5.5V Input Range
  • 0.6V to 5.0V Resistor Configurable Output Voltages
  • Jumper Selectable Between Two Output Voltages
  • Input to Output Pass-Through Mode
  • Up to 1A Output Current
  • Proven 4-Layer 1-oz Copper PCB Layout
  • Demonstrates Compact Solution Size
  • Fully Assembled and Tested

Product Details

The MAX38913A WLP evaluation kit (EV kit) evaluates the MAX38913A in a wafer-level package (WLP). The MAX38913A is a low-noise linear regulator. The EV kit operates over an input range of 1.8V to 5.5V. The EV kit provides an output voltage that is jumper selectable between two separate levels. Each of the two regulated output levels are configured to one of the 33 possible voltages through external select resistors. The MAX38913A EV kit features a pass-through mode that can completely bypass the linear regulator. The EV kit can deliver up to 1A of current.

Applications

  • Image Sensors
  • Portable Sensor Applications
  • SD Memory Cards
MAX38913AEVK
Evaluation Kit for the MAX38913 and MAX38914
MAX38913AEVK Board Photo Angle View MAX38913AEVK Board Photo Top MAX38913AEVK Board Photo Bottom View
