MAX38886

2.5V to 5.0V, 0.5A/2.5A, Charge/Discharge Regulator for Supercapacitor Backup Applications

Show More showmore-icon

Continua™ Family of Backup Power Regulators Using Supercapacitor or Capacitor Bank

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Viewing: Part Details
arrow-icon

Not the part you were looking for?

viewall Go to Product Selection Table
file View Data Sheet (Rev.0)
Documentation View All Documentation
Part Models 2
1ku List Price Starting From $2.24
Features
  • 2.5V to 5V System Output Voltage
  • Up to 4.5V Capacitor Voltage Range
  • Up to 2.5A Peak Inductor Discharge Current
  • Programmable Voltage and Current Thresholds
  • ±2% Threshold Accuracy
  • Up to 95% Efficiency, Charge or Discharge
  • 2.5μA Ready Quiescent Current
  • Small Solution Size
    • 3mm x 3mm x 0.75mm TDFN Package
Additional Details
show more Icon

The MAX38886 is a storage capacitor or capacitor bank backup regulator designed to efficiently transfer power between a storage element and a system supply rail in reversible buck and boost operations using the same inductor.

When the main supply is present and above the minimum system supply voltage, the regulator operates in buck mode and charges the storage element at up to 500mA peak inductor current. Once the storage element is charged, the circuit draws only 2.5μA of current while it maintains the supercapacitor or other storage element in its ready state. When the main supply is removed, the regulator operates in boost mode and prevents the system from dropping below the minimum operating voltage, discharging the storage element at up to 2.5A peak inductor current.

The MAX38886 is externally programmable for minimum and maximum voltage of the storage element, such as supercapacitor, minimum system voltage, and maximum charge and discharge currents. The internal DC-DC converter requires only a 1µH inductor.

Applications

  • Handheld Industrial Equipment
  • Portable Computers
  • Portable Devices with a Removable Battery
Show More Arrow image
file View Data Sheet (Rev.0)
Documentation View All Documentation
Part Models 2
1ku List Price Starting From $2.24
modal bookmark icon

{{modalTitle}}

modal close icon

{{modalDescription}}

{{dropdownTitle}}

input down arrow
  • {{defaultSelectedText}}
    • {{#each projectNames}}
  • {{name}}
    • {{/each}} {{#if newProjectText}}
  • plus icon {{newProjectText}}
    • {{/if}}
{{#if toggleButtonDescription}}
{{toggleButtonDescription}}
{{/if}} {{#if newProjectTitle}}

{{newProjectTitle}}

{{projectNameErrorText}}

{{/if}}

MAX38886

Documentation

2
overlayclose

Filters

1 Applied

mobileoverlaydownarrow
  • All
    TickIcon
  • Data Sheet
  • Design Note
  • All
    TickIcon
  • English
resetfilter

Reset Filters

Data Sheet

1

PDF Vector

PDF

UPDATED 09/25/2020
English

MAX38886: 2.5V to 5.0V, 0.5A/2.5A, Charge/Discharge Regulator for Supercapacitor Backup Applications Data Sheet (Rev.0)

Open PDF File

redirect
623.00K
download

Download PDF

Design Note

1

PDF Vector

HTML

UPDATED 09/20/2021
English
Voltage balancing techniques for series super capacitor connection for MAX38886/8/9 redirect icon

There are no results matching this criteria. Try resetting your filters or searching for a different term

close icon

Documentation

Video

1

Thumbnail Image

Video

2022-10-04

05:02

Introduction to the MAX38886 2.5V–5.0V, 0.5A/2.5A Super-Capacitor Charge/Discharge Backup Regulator

Learn More
Show More Arrow image

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX38886ATD+ Thin Dual Flatpack No Leads external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link
MAX38886ATD+T Thin Dual Flatpack No Leads external-link
  • HTML
  • Material Declaration external-link
  • HTML
  • Reliablity Data external-link

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Apr 27, 2024

- 2400

ASSEMBLY

MAX38886ATD+

PRODUCTION

MAX38886ATD+T

PRODUCTION

pdf

pcn_2400

external-icon

Apr 23, 2024

- 2419N

ASSEMBLY

MAX38886ATD+

PRODUCTION

MAX38886ATD+T

PRODUCTION

pdf

pcn_2419n

external-icon

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Apr 27, 2024

- 2400

arrow down

ASSEMBLY

MAX38886ATD+

PRODUCTION

MAX38886ATD+T

PRODUCTION

pdf

pcn_2400

external-icon
Apr 23, 2024

- 2419N

arrow down

ASSEMBLY

MAX38886ATD+

PRODUCTION

MAX38886ATD+T

PRODUCTION

pdf

pcn_2419n

external-icon

Software & Part Ecosystem

Parts Product Life Cycle Description

Internal Power Switch Boost Regulators1
MAX38888
popup image
Cart

PRODUCTION

2.5V–5.0V, 0.5A/2.5A Reversible Buck/Boost Regulator for Backup Power Applications

Evaluation Kits 1

MAX38886EVKIT

Evaluation Kit for the MAX38886

zoom

MAX38886EVKIT

Evaluation Kit for the MAX38886

download icon

Download

 print icon

Print
MAX38886EVKIT
Evaluation Kit for the MAX38886

Features and Benefits

  • 2.99V to 3.36V System Output Voltage Range
  • 0.5V to 2.71V Super Cap Voltage Range
  • 2.5A Peak Discharge Current
  • Resistor-Adjustable Voltage and Current Thresholds
  • Proven 2-Layer, 2oz Copper PCB Layout
  • Compact Solution Size
  • Fully Assembled and Tested
Buy Now View Details

Product Detail

The MAX38886 evaluation kit (EV kit) evaluates the MAX38886 IC. The MAX38886 is a super cap backup regulator designed to transfer power between a super cap and a system supply rail. When the main battery is present and above the minimum system supply voltage, the regulator charges the super cap at up to a 500mA rate. Once the super cap is charged, the circuit draws only 3µA of current while it maintains the super cap in its ready state. When the main battery is removed, the regulator prevents the system from dropping below the minimum operating voltage, discharging the super cap at up to a 2.5A peak inductor current. Multiple MAX38886 ICs can be connected in parallel for higher current applications. The MAX38886 is externally programmable for mini- mum and maximum super cap voltage, minimum system voltage, and maximum charge and discharge currents. The internal DC-DC converter requires only a 1µH inductor and a 22µF capacitor.

Applications

  • Handheld Industrial Equipment
  • Portable Computers
  • Portable Devices with a Removable Battery

Resources

pdf icon

PDF

MAX38886EVKIT BOM Download

38.68K

pdf icon

ZIP

MAX38886EVKIT ODB Files - Design Files Download

805.02 K

Show More Arrow image

Evaluation Kits1

MAX38886EVKIT

Evaluation Kit for the MAX38886
