MAX32558
DeepCover Secure ARM Cortex-M3 Flash Microcontroller
Low Footprint Secure SoC Microcontroller for mPOS with Secure Boot Loader
Top
Overview
Features and Benefits
- ARM Cortex-M3 Processor Core Allows for Easy Integration into Applications
- 60MHz Core Operating Frequency Through PLL
- 512KB Dual-Bank Flash Memory with Cache
- 96KB System SRAM
- 1KB AES Self-Encrypted NVSRAM
- Security Features Facilitate System-Level Protection
- Secure Boot Loader with Public Key Authentication
- AES, DES and SHA Hardware Accelerators
- Modulo Arithmetic Hardware Accelerator (MAA) Supporting RSA, DSA, and ECDSA
- 4x3 Secure Keypad Controller
- Hardware True Random-Number Generator
- Die Shield with Dynamic Fault Detection
- 4 External Tamper Sensors with Independent Random Dynamic Patterns
- 256-Bit Flip-Flop-Based Battery-Backup AES Key Storage
- Temperature and Voltage Tamper Monitor
- Real-Time Clock
- Integrated Peripherals Reduce External Component Count
- Triple-Track Magnetic Stripe Head Interface
- One ISO 7816 Smart Card Interface with Integrated Transceiver (1.8V, 3V, and 5V)
- USB 2.0 Device with Internal Transceiver and Dedicated PLL
- 1 SPI Port, 1 UART Port, and 1 I2C Controller
- 8 Timers, with up to 2 PWM I/O
- Up to 27 General-Purpose I/O Pins
- 1-Channel, 10-Bit ADC
- 4-Channel DMA Controller
- Power Management Optimizes Battery Life and Reduces Active Power Consumption
- Single 3.3V Supply Operation*
- Integrated Battery-Backup Switch
- Clock Gating Function
- Low-Current Battery-Backup Operation
Product Details
DeepCover® embedded security solutions cloak sensitive data under multiple layers of advanced physical security to provide the most secure key storage possible.
The MAX32558 is based on an Arm® Cortex®-M3 processor with 512KB of embedded flash, 96KB of system RAM, 1KB of battery-backed AES self-encrypted NVSRAM. It includes a cryptographic engine, a true random number generator, battery-backed RTC, environmental and tamper detection circuitry, a magnetic stripe reader, a smart card controller with embedded transceiver to directly support 1.8V, 3.3V, and 5V cards, and an integrated secure keypad controller. It also includes a vast array of peripherals, USB SPIs, UARTs, DMA, and ADC that add flexibility to control and differentiate the system design.
Applications
- ATM Keyboards
- EMV Card Readers
- HSMs
- Industrial Modules
- PCI Mobile Payment Terminals (mPOS)
- Standalone Smartcard Readers
