MAX20812

RECOMMENDED FOR NEW DESIGNS

Dual-Output 6A, 3Mhz, 2.7V to 16V, Step-Down Switching Regulator

Shrink Your Designs with Smallest and Fastest Two Regulators in One Package

Data Sheet (Rev. 3) Product Selection Table
Viewing:

Overview

  • High Power Density with Low Component Count
    • Dual-Output or Dual-Phase Operation
    • Single-Supply Operation with Integrated LDO for Bias Generation
    • Optional 2.5V to 5.5V External Bias for Higher Efficiency
    • Compact 3.5mm x 4.6mm, 21-Pin, FC2QFN Package
    • Internal Compensation
  • Wide Operating Range
    • 2.7V to 16V Input Voltage Range
    • 0.5V to 5.8V Output Voltage Range
    • 500kHz to 3MHz Configurable Switching Frequency
    • -40°C to +125°C Junction Temperature Range
    • Three Pin-Strap Programming Pins to Select Different Configurations
    • Independent Enable and Power Good for Each Output
  • Optimized Performance and Efficiency
    • 92.5% Peak Efficiency with VDDH = 12V, VOUT = 1.8V, and fSW = 1MHz
    • Interleaved 180° Out-of-Phase Operation
    • Selectable AMS to Improve Load Transient
    • Selectable DCM to Improve Light Load Efficiency
    • Active Current Balancing for Dual-Phase Operation (MAX20812 only)

The MAX20812/MAX20812T is a dual-output, fully integrated, highly efficient, step-down DC-DC switching regulator. These regulators are able to operate from 2.7V to 16V input supplies, and each output can be regulated from 0.5V to 5.8V, delivering up to 6A of load current per output. With the MAX20812, the two outputs can be connected in parallel as a single-output, dual-phase regulator that supports up to 12A load current.

The switching frequency of this device can be configured from 500kHz to 3.0MHz and provides the capability of optimizing the design in terms of solution size and performance.

The MAX20812/MAX20812T utilizes fixed-frequency, current-mode control with internal compensation. The dual-switching regulators operate 180° out-of-phase. The MAX20812 features a selectable advanced modulation scheme (AMS) to provide improved dynamic load transient performance. The device also features selectable discontinuous current mode (DCM) operation to improve light load efficiency. Operation settings and configurable features can be selected by connecting pin-strap resistors from the PGM_ pins to ground.

The MAX20812/MAX20812T has an internal 1.8V LDO output to power the gate drives (VCC) and internal circuitry (AVDD). The device also has an optional LDO input pin (LDOIN), allowing connection from a 2.5V to 5.5V bias input supply for optimized efficiency.

The MAX20812/MAX20812T integrates multiple protections including positive and negative overcurrent protection, output overvoltage protection, and overtemperature protection to ensure a robust design.

The MAX20812/MAX20812T is available in a compact 3.5mm x 4.6mm FC2QFN package that supports -40°C to +125°C junction temperature operation. The MAX20812 package has an open top, and the MAX20812T package has a closed top.

APPLICATIONS

  • Data Center Power
  • Communications Equipment
  • Networking Equipment
  • Servers and Storage
  • Point-of-Load Voltage Regulators
MAX20812
Dual-Output 6A, 3Mhz, 2.7V to 16V, Step-Down Switching Regulator
MAX20812: Block Diagram
Add to myAnalog

Add product to the Products section of myAnalog (to receive notifications), to an existing project or to a new project.

Create New Project
Ask a Question

Documentation

Data Sheet 1

Application Note 1

Learn More
Add to myAnalog

Add media to the Resources section of myAnalog, to an existing project or to a new project.

Create New Project

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

EE-Sim Power® Tools 3

The EE-Sim DC-DC Converter Tool uses your requirements to quickly create a complete power design including a schematic, BOM with commercially available parts, and time and frequency domain simulations. Your customized schematic can be downloaded for further analysis in the standalone EE-Sim OASIS Simulator, featuring SIMPLIS and SIMetrix SPICE engines.

Start EE-Sim Now Start EE-Sim Now Start EE-Sim Now

SIMPLIS Models 1

Evaluation Kits

MAX20812EVKIT

Evaluation Kit for the MAX20812/MAX20812T

Buy Now View Details

Features and Benefits

  • 2.7V to 16V Input Voltage Range
  • 0.5V to 5.8V Output Voltage Range
  • High Efficiency and Power Density
  • Low Component Count
  • Dual-Output (MAX20812/MAX20812T) or Single- Output Dual-Phase Operation (MAX20812)
  • Optimized Performance
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Details

The MAX20812 evaluation kit (EV kit) is a reference platform designed for the evaluation of the MAX20812/ MAX20812T, a dual-output, compact, low-cost, fully integrated, highly efficient, step-down DC-DC switching regulator IC. The IC is available in a 21-pin, 3.5mm x 4.6mm, 0.5mm pitch, FC2QFN package. This EV kit can deliver up to 6A load per output. For the MAX20812, the two outputs can be connected as a single-output, dual-phase regulator that supports up to 12A load current. Refer to the MAX20812 IC data sheet for more information.

The EV kit comprises a fully assembled and tested PCB implementation of the MAX20812/MAX20812T. Jumper pins, test points, and input/output connectors are included for flexibility and convenience in a wide range of applications..

Applications

  • Communications Equipment
  • I/O Pins of an FPGA/DSP/MCU
  • Memory VDDQ
  • Networking Equipment
  • Point-of-Load Voltage Regulators
  • Servers and Storage Equipment
  • μP Chipsets
MAX20812EVKIT
Evaluation Kit for the MAX20812/MAX20812T
