Features and Benefits
- Multiple Functions for Small Size
- Operating VIN Range of 3V to 36V
- 10µA Quiescent Current in Skip Mode
- Synchronous DC-DC Converter with Integrated FETs
- 400kHz, 2.1MHz, and 3MHz Fixed Frequency Options
- Fixed 2.5ms Internal Soft-Start
- Programmable 0.8V to 10V Output, or Fixed-OutputVoltages of 3.3V, 3.9V, 4.2V, and 5.0V
- Other Fixed-Output Options Available between 2.9Vto 6V in 100mV Steps
- 3.5mm x 3.75mm, 17-Pin and 15-Pin FC2QFN
- Symmetrical package offers superior EMI performance
- Dual-Phase Capablity
- Can be used in Dual-Phase Configuration for High Power Design
- Dynamic Current Sharing through Shared VEA Pin
- Low-IQ Operation Capability in Dual Phase
- High Precision
- ±1% Output-Voltage Accuracy in FPWM Mode at No Load
- Precise Output Voltage Monitoring with PGOOD
- Robust for the Automotive Environment
- Forced-PWM and Skip Mode Operation
- 99% Duty-Cycle Operation with Low Dropout
- Overtemperature and Short-Circuit Protection
- -40°C to +125°C Junction Operating Temperature Range
- 42V Load-Dump Tolerant
- AEC-Q100 Qualified
The MAX20404/MAX20405/MAX20406/MAX20406E ICs are tiny synchronous buck converters with integrated high-side and low-side switches. The ICs are designed to deliver up to 6A with wide input voltages range from 3V to 36V. Voltage quality can be monitored by observing the PGOOD signal. The MAX20404/MAX20405/MAX20406/MAX20406E can operate in dropout by running at 99% duty cycle making it ideal for automotive and industrial applications.
The MAX20404/MAX20405/MAX20406/MAX20406E offer programmable or fixed output voltages of 5V and 3.3V. Frequency is internally fixed at 2.1MHz (or 400KHz or 3MHz) which allows for small external components, reduced output ripple, and guarantees no AM interference. MAX20404/MAX20405/MAX20406/MAX20406E automatically enter skip mode at light loads with ultra-low quiescent current of 10µA at no load. This family of products (including the MAX20408/10) offers a pin-to-pin compatible offering from 4A to 10A in a single-phase configuration, and up to 20A in a dual-phase configuration. This devices have also been optimized for dual-phase operation with very high current sharing accuracy. These devices can be ordered with spread-spectrum frequency modulation designed to minimize EMI-radiated emissions due to the modulation frequency.
The MAX20404/MAX20405/MAX20406/MAX20406E are available in a small 3.5mm x 3.75mm 17-pin FC2QFN package and uses very few external components.
- Infotainment Systems
- ADAS and Other Safety-Critical Applications
- High-Voltage DC-DC Converters
Markets and Technologies
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The MAX20406 evaluation kit (EV kit) provides a proven design to evaluate the MAX20406 automotive 2.1MHz synchronous buck converter with 10µA quiescent current. The standard EV kit PCB comes with a MAX20406AFOB/ VY+ (2.1MHz, 3.3V) installed, as well as various test points and jumpers for evaluation. The EV kit output voltage is fixed and easily configured with minimum component changes. The default EV kit is designed to deliver up to 6A with input voltage 3V to 36V. Output voltage quality can be monitored by observing the PGOOD signal. The MAX20406 EV kit can also be used to evaluate the MAX20404 and MAX20405.
- Automotive ADAS and other safety critical applications
- Automotive Infotainment Systems
- High-Voltage DC-DC Converters
Features & Benefits
- Input Supply Range from 3V to 36V
- Output Voltage: 3.3V/5V Fixed and Adjustable from 0.8 to 10V
- Delivers up to 6A
- Frequency - Synchronization Input
- Enable Input
- Spread Spectrum Available
- Voltage Monitoring PGOOD Output Available
- Proven PCB Layout
- Fully Assembled and Tested
