Features and Benefits
- Meets Stringent OEM Module Power Consumption and Performance Specifications
- 10µA Supply Current with 5V Buck On
- 8µA Supply Current with 3.3V Buck On
- 30µA Supply Current with All Regulators On
- Enables Crank-Ready Designs
- Output Voltages in Regulation Through Cold CrankDown to 2V Battery Voltage
- Wide Input-Supply Range from 3.5V to 36V
- EMI Reduction Features Reduce Interference with Sensitive Radio Bands without Sacrificing Wide Input-Voltage Range
- 20ns (typ) Minimum On-Time Guarantees Skip-Free Operation for 3.3V Output at 2.1MHz
- Spread-Spectrum Option
- Phase-Locked Loop (PLL) Frequency Synchronization
- Integration and Thermally Enhanced Packages Save Board Space and Cost
- Two 2.1MHz Buck Converters with Asynchronous Boost Controller
- Current-Mode Controller with Forced Fixed-Frequency and Skip Modes
- Thermally Enhanced 5mm x 5mm, 28-Pin TQFN-EP Package
- Protection Features Improve System Reliability
- Supply Undervoltage Lockout
- Overtemperature and Short-Circuit Protection
The MAX20057 is an automotive highly integrated triple-output PMIC. It includes two synchronous buck converters and an asynchronous boost controller with 2.1MHz and 400kHz options. The boost controller can be used to provide power to buck converters and keep them in regulation during cold-crank operation down to 2V battery input. Two high-voltage synchronous step-down converters operate 180° out-of-phase. The IC operates with an input voltage supply from 3.5V to 36V and can operate in dropout conditions by running at 95% duty cycle. It is intended for applications with mid- to high-power requirements that operate at a wide input voltage range such as during automotive cold-crank or engine stop-start conditions.
High switching frequency up to 2.1MHz allows small external components, reduced output ripple, and guarantees no AM band interference. The switching frequency is fixed at 400kHz or 2.1MHz. FSYNC input programmability enables three modes for optimized performance: forced fixed-frequency operation, skip mode with ultra-low quiescent current, and phase-locked synchronization to an external clock. The spread spectrum option minimizes EMI interference.
The IC features the power-OK indicators for buck converters and undervoltage lockout for each power rail. Protection features include cycle-by-cycle current limit and thermal shutdown. The MAX20057 is specified for operation over the -40°C to +125°C automotive temperature range.
- ● Navigation and Radio Head Units
Product Lifecycle Recommended for New Designs
This product has been released to the market. The data sheet contains all final specifications and operating conditions. For new designs, ADI recommends utilization of these products.
Evaluation Kits (1)
The MAX20057 evaluation kit (EV kit) is a fully assembled and tested application circuit that simplifies the evaluation of the MAX20057 400kHz/2.1MHz, 36V boost controller and dual buck converters. All installed components are rated for the automotive temperature range. Various test points and jumpers are included for evaluation.
The standard EV kit comes with the MAX20057ATIE/VY+ installed (5V, 3.3V, 2.1MHz), but can also be used to evaluate other MAX20057 variants with minimal component changes shown in the MAX20057 EV Kit Bill of Materials.
- Automotive Start-Stop System
- Distributed DC Power Systems
- Instrument Cluster
- Navigation and Radio Head Units
Features & Benefits
- Dual High-Voltage Step-Down Converters with Integrated Power FETs to Minimize Board- Area-Occupancy
- Asynchronous Boost Controller
- 3.5V to 40V Input Supply Range
- Input Supply Range Extended Down to 2V with Boost Preenabled
- 10V Fixed Boost Output Voltage
- Buck1 Provides 5V Output Up To 3.5A Output Current
- Buck2 Provides 3.3V Output Up To 2A Output Current
- Buck Output Voltages Adjustable Between 1V and 10V Using External Resistors
- ±2% Output Voltage Accuracy for Buck Converters
- Selectable Buck2 Input Source
- Frequency-Synchronization Input
- Independent Enable Inputs
- Voltage-Monitoring PGOOD Outputs
- Jumpers and Test Points on Key Nodes for Simplified Evaluation
- Proven PCB Layout
- Fully Assembled and Tested
