3.2MHz, 500mA Dual Step-Down Converters for Automotive Cameras

Ultra-Small 3.2MHz Dual 500mA Versatile PMIC for Camera Modules

Data Sheet (Rev. 0) Product Selection Table
Part Models
16
1ku List Price
Starting From $2.03
Viewing:

Part Details

  • Small Solution Size
    • 2mm x 3mm x 0.75mm 10-pin TDFN with an Exposed Pad
    • 2.2MHz and 3.2MHz Operation Allows Smaller System Size
    • No External Components Needed for Soft-Start
  • Cable Flexibility
    • 500mV Enable Hysteresis Allows for Long, Low-Cost Cables During Slow Starts
  • EMI Solutions
    • Optional Spread-Spectrum Frequency Modulation
    • Pinout Placement Allows for Tight PCB Layout of Switching Nodes
  • Self-Protected
    • Overvoltage Protection, Thermal Shutdown, Short-Circuit Protection
  • Automotive Ready
    • Wide 3.5V to 17V Input Voltage Range for Power-Over-Coax
    • Automotive Temperature Range -40°C to +125°C
    • AEC-Q100 Qualified
MAX20019
3.2MHz, 500mA Dual Step-Down Converters for Automotive Cameras
MAX20019, MAX20020: Functional Diagrams
