Features and Benefits
- High-Efficiency DC-DC Converter
- Up to 12A Peak Output Current
- MAX20011A: 8A
- MAX20011B: 12A
- Differential Remote Voltage Sensing
- 3.0V to 5.5V Operating Supply Voltage
- I2C-Controlled Output Voltage: 0.5V to 1.275V in 6.25mV Steps
- Excellent Load-Transient Performance
- Programmable Compensation
- 2.2MHz or 1.1MHz Operation
- ±1.5% Output-Voltage Accuracy
- Active-Low RESET Output
- Current-Mode, Forced-PWM Operation
- ASIL C Compliant
- Redundant Reference
- BIST Diagnostics
- PEC on I2C
- Programmable OV/UV with ±1% Accuracy
- Overtemperature and Short-Circuit Protection
- 3.5mm x 3.75mm, 17-Pin Side-Wettable FC2QFN
- -40°C to +125°C Grade 1 Automotive Temperature Range
The MAX20011 is a family of high-efficiency, synchronous step-down converters that operate with a 3.0V to 5.5V input voltage range and supply a 0.5V to 1.275V output voltage range. The wide input/output voltage range and the ability to provide up to 12A peak output current make this device family ideal for on-board point-of-load and post-regulation applications. The MAX20011 achieves ±1.5% output error over load, line, and temperature ranges.
The MAX20011 features a 2.2MHz fixed-frequency PWM mode for better noise immunity and load-transient response. The 2.2MHz frequency operation allows for the use of all ceramic capacitors and minimizes external components. The spread-spectrum frequency modulation option minimizes radiated electromagnetic emissions. Integrated low RDS(ON) switches improve efficiency at heavy loads and make layout simpler than discrete solutions.
The MAX20011 is offered with factory-preset output voltage. See the Ordering Information table for options. The I2C interface supports dynamic voltage adjustment with programmable slew rates. Other features include programmable soft-start, overcurrent, and overtemperature protections.
- Automotive ADAS Systems
- SoC Core Power
Markets and Technologies
Product Lifecycle Production
At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
Evaluation Kits (1)
The MAX20011B EV kit is a fully assembled and tested PCB intended to demonstrate the capability of the MAX20011B step-down (buck) voltage regulator. MAX20011B has output current rating of 12A. The IC operates at 3V to 5.5V input supply voltage and can regulate to a voltage range of 0.5V to 1.275V.
The device features a 2.2MHz fixed-frequency PWM mode for better noise immunity and load-transient response. The 2.2MHz frequency operation allows for the use of all ceramic capacitors and minimizes external components. The programmable spread-spectrum frequency modulation minimizes radiated electromagnetic emissions. Integrated low RDS(ON) switches improve efficiency at heavy loads and make the layout a much simpler task with respect to discrete solutions.
The I2C interface supports dynamic voltage adjustment with programmable slew rates. Other features include programmable soft-start, overcurrent, and overtemperature protections.
The EV kit comes pre-tested for immediate evaluation.
- Automotive ADAS Systems
- SoC Core Power
Features & Benefits
- Full Silicon Integration Allows for Improved Efficiency and Minimized Space
- Input Voltage Range From 3.0V to 5.5V
- Output Voltages Range From 0.5V to 1.275V
- I2C Controlled Output Voltage (6.25mV Steps)
- Excellent Load-Transient Response
- Internally Programmable Compensation
- High Switching Frequency of 2.2MHz
- Forced PWM Mode
- Enable and Reset Connections Available
- Loop Measurements Ready
- Proven PCB Layout
- Fully Assembled and Tested
