Overview

Features and Benefits

  • Multiple Functions for Small Size
    • Operating VIN Range of 3V to 36V
    • 15µA Quiescent Current in Skip Mode
    • Synchronous DC-DC Converter with Integrated FETs
    • 400kHz/2.2MHz Frequency versions
    • Fixed 5ms Internal Soft-Start
    • Programmable 1V to 10V Output, or 3.3V and 5.0V Fixed-Output Options Available
    • 98% Duty-Cycle Operation with Low Dropout
    • Active-low RESET output
  • High Precision
    • ±2% Output-Voltage Accuracy
    • Good Load-Transient Performance
  • Robust for the Automotive Environment
    • Current-Mode, Forced-PWM and Skip Operation
    • Overtemperature and Short-Circuit Protection
    • 3.5mm x 3.75mm 17-Pin FC2QFN
    • Symmetrical Pinout with Pin-Selectable Spread Spectrum for Optimized EMI Performance
    • -40°C to +150°C Junction Operating Temperature Range
    • 40V Load-Dump Tolerant
    • AEC-Q100 Qualified

Product Details

The MAX20004E/MAX20006E/MAX20008E are small, synchronous buck converters with integrated high-side and low-side MOSFETs. The device family can deliver up to 8A with input voltages from 3V to 36V, while using only 15µA quiescent current at no load (except for MAX20006EAFOD/VY+ which has FPWM mode only). Voltage quality can be monitored by observing the active-low RESET signal. The devices can operate in dropout by running at 98% duty cycle, making them ideal for automotive applications.

The devices offer fixed output voltages of 5V, 3.9V, or 3.3V. Compensation is internal to the device, providing excellent transient response. Frequency can be 400kHz or 2.1MHz. The devices offer a forced fixed-frequency mode and skip mode with ultra-low quiescent current of 15µA. The device has a pin-selectable (SSEN) spread-spectrum enable to further assist systems designers with better EMC management.

The MAX20004E/MAX20006E/MAX20008E are available in a small, 3.5mm x 3.75mm, 17-pin FC2QFN package and use very few external components.

Applications

  • ADAS
  • Distributed DC Power Systems
  • Navigation and Radio Head Units
  • Point-of-Load Applications in Automotive

Product Lifecycle icon-recommended Production

At least one model within this product family is in production and available for purchase. The product is appropriate for new designs but newer alternatives may exist.
