MAX17702

4.5V to 60V, Synchronous Step-Down Lead-Acid Battery Charger Controller

Show More showmore-icon

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Details
Part Models 2
1ku List Price Starting From $2.81
Features
  • Optimized Feature-Set for Pb-Acid Batteries
    • ±4% Charging Current Regulation Accuracy
    • ±6% Charging Current Monitor Accuracy (ISMON)
    • ±1% Voltage Regulation Accuracy
    • Programmable Constant Current (CC) Mode Charging Current (ILIM)
    • Full-Battery Detection with Taper Current Threshold and Absorption CV Timer (TMR)
    • Wide 4.5V to 60V Input-Voltage Range
    • Adjustable Output-Voltage Range from 1.25V up to Four 12V Pb-Acid Batteries in Series
    • 125kHz to 2.2MHz Adjustable Frequency with External Clock Synchronization (RT/SYNC)
  • Reliable Operation in Adverse Environmental Conditions
    • Input Short-Circuit Protection (GATEN)
    • Deeply Discharged Battery Detection and Preconditioning (DDTH)
    • Battery Temperature Sensing and Charge when Within Temperature of Range (TEMP)
    • Output Voltage Temperature Compensation
    • Cycle-by-Cycle Overcurrent Limit
    • Programmable EN/UVLO Threshold
    • Status Output Monitoring Using Open-Drain Outputs (FLG1 and FLG2)
    • Overtemperature Protection
    • Complies with CISPR 32 (EN55032) Class B Conducted and Radiated Emissions
    • Wide -40°C to +125°C Ambient Operating Temperature Range/ -40°C to +150°C Junction Temperature Range
Additional Details
show more Icon

The Himalaya series of voltage regulator ICs, power modules, and chargers enable cooler, smaller, and simpler power supply solutions. The MAX17702 is a high-efficiency, high-voltage, synchronous, step-down, Himalaya lead-acid (Pb-acid) battery charger controller designed to operate over an input-voltage range of 4.5V to 60V. The MAX17702 operates over a wide -40°C to +125°C temperature range and offers a complete charging solution for Pb-acid batteries with a ±4% accurate constant-current regulation. The output voltage is programmable from 1.25V up to (VDCIN - 2.1V) with ±1% regulation accuracy.

The device uses an external nMOSFET to provide input supply-side short-circuit protection, preventing battery discharge.

The device charges the battery in constant current (CC), absorption constant voltage (CV) states and enters floating CV state after detecting taper current threshold or absorption CV timer timeout in Absorption CV state. Detection and preconditioning of deeply discharged batteries are enabled by a deep discharge detection comparator.

he MAX17702 is available in a 24-pin 4mm x 4mm TQFN package with an exposed pad.

Applications

  • Battery Backup for Lighting, Security Cameras, and Control Panels
  • Building and Home-Automation Backup Power
  • Industrial Battery Charging and Energy Storage
  • Portable Industrial Equipment
  • Power Tools
Part Models 2
1ku List Price Starting From $2.81

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX17702ATG+
  • HTML
  • HTML
MAX17702ATG+T
  • HTML
  • HTML
Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 1

MAX17702EVKITA

Evaluation Kit for the MAX17702 in 13.8V Lead-Acid Battery Charger Application

zoom

MAX17702EVKITA

Evaluation Kit for the MAX17702 in 13.8V Lead-Acid Battery Charger Application

Evaluation Kit for the MAX17702 in 13.8V Lead-Acid Battery Charger Application

Features and Benefits

  • Operates from a 19V to 60V Input Supply
  • 10A CC Mode Charging Current
  • 13.8V Absorption CV Voltage and 13.5V Floating CV Voltage
  • 350kHz Switching Frequency
  • Resistor-Programmable UVLO Threshold (EN/UVLO)
  • Input Short Protection
  • 11V Programmed Deeply Discharged Battery Detection
  • Capacitor Programmed 17 Hours Absorption CV Timer
  • Full-Battery Detection with Taper Current Threshold or Absorption CV Timer
  • Cycle-by-Cycle Overcurrent Limit
  • External Clock Synchronization (RT/SYNC)
  • Charger Status Flags (FLG1 and FLG2)
  • Charging Current Monitoring (ISMON)
  • Battery Temperature Sensing and Charge when Within Operating Temperature Range of -20°C to +60°C
  • Charging Voltage Temperature Compensation (-18mV/°C)
  • IC Overtemperature Protection
  • Proven PCB Layout
  • Fully Assembled and Tested
  • Complies with CISPR 32 (EN55032) Class B Conducted and Radiated Emissions

Product Detail

The MAX17702EVKITA# (EV kit) provides a proven design to evaluate the MAX17702 high-efficiency, high-voltage, Himalaya synchronous step-down DC-DC lead-acid (Pb-acid) charger controller. The EV kit charges the Pb-acid battery in constant current (CC), absorption constant-voltage (CV) states, and enters an floating CV state after detecting the taper current threshold or absorption CV timer timeout in the absorption CV state. The EV kit is designed to charge the Pb-acid battery with 10A CC mode charging current (ICHGMAX) and 13.8V absorption CV voltage (VOUT) from a 19V to 60V input supply. The EV kit is optimized for 24V nominal input-voltage application. The switching frequency of the EV kit is set at 350kHz (fSW) for optimum efficiency and component size. The EV kit features an absorption CV timer (TMR) to set the maximum charging time in the absorption CV state. The EV kit features battery temperature sensing and charges only when the temperature is in the allowable charging temperature range. The EV kit also features the charging voltage temperature compensation based on battery temperature. The EV kit also provides a good layout example, which is optimized for conducted, radiated EMI and thermal performance. For more details about the IC benefits and features, refer to the MAX17702 IC data sheet.

Applications

  • Battery Backup for Lighting, Security Cameras, and Control Panels
  • Building and Home-Automation Backup Power
  • Industrial Battery Charging and Energy Storage
  • Portable Industrial Equipment
  • Power Tools
