MAX16137

1% Accuracy Single-Window Voltage Monitor with BIST

Show More showmore-icon

Provide More Diagnostics in Half the Size

Info : RECOMMENDED FOR NEW DESIGNS tooltip
Info : RECOMMENDED FOR NEW DESIGNS tooltip
Part Details
Part Models 4
1ku List Price Starting From $1.25
Features
  • ±1% Allow Precision Supply Monitoring
  • BIST Enhances System Safety
  • Enables ASIL Compliance at System Level
  • Factory-Set Threshold 0.5V to 5V with 20mV Increment
  • Factory-Set Input Tolerance ±4% to ±11% UV/OV Threshold Window
  • Factory-Set Reset Timeout
  • Latched Overvoltage Fault Output
  • 5μs Overvoltage Fault Response
  • Open-Drain/Push-Pull Reset Output
  • 2mm x 2mm TDFN-8 Side-Wettable Package
  • -40°C to +125°C Temperature Range
  • AEC-Q100 Qualified
Additional Details
show more Icon

The MAX16137 is a low-voltage, ±1% accurate supervisory circuit that monitors a single system supply voltage for undervoltage and overvoltage faults within a factory-set threshold window. When the monitored supply voltage drops below the undervoltage threshold or goes above the overvoltage threshold, the reset output asserts low. The reset output deasserts after the reset timeout period when the supply voltage returns to within the undervoltage and overvoltage threshold window. The reset output is active-low available in either the push-pull or open-drain options.

The MAX16137 offers factory-trimmed nominal input voltage options from 0.5V to 5V in approximately 20mV increment. A variety of factory-trimmed undervoltage/overvoltage thresholds from ±4% to ±11% are available to accommodate different supply voltages and tolerances.

The MAX16137 features a unique Built-In-Self-Test (BIST) diagnostic capability that monitors the health of the internal reset circuit during power-up. If the built-in-self-test fails, the MAX16137 asserts active-low BIST low. During normal operation, the MAX16137 performs an on-demand BIST when the active-low CLR/BIST is pulled low for more than 150μs. See the Built-In-Self-Test section for more details.

The MAX16137 is available in a small, 2mm x 2mm, 8-pin TDFN side-wettable package with exposed pad and operates over the automotive temperature range of -40°C to +125°C.

Applications

  • Advanced Driver-Assistance Systems (ADAS)
  • Multivoltage ASICs
  • Servers
  • Storage Equipment
Part Models 4
1ku List Price Starting From $1.25

close icon
Documentation

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX1613700/VY+
  • HTML
  • HTML
MAX1613700/VY+T
  • HTML
  • HTML
MAX1613701/VY+
  • HTML
  • HTML
MAX1613701/VY+T
  • HTML
  • HTML

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Jul 14, 2022

- 2290

ASSEMBLY

MAX1613700/VY+

PRODUCTION

MAX1613700/VY+T

PRODUCTION

MAX1613701/VY+

PRODUCTION

MAX1613701/VY+T

PRODUCTION

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Jul 14, 2022

- 2290

arrow down

ASSEMBLY

MAX1613700/VY+

PRODUCTION

MAX1613700/VY+T

PRODUCTION

MAX1613701/VY+

PRODUCTION

MAX1613701/VY+T

PRODUCTION

Software & Part Ecosystem

Software & Part Ecosystem

Evaluation Kit

Evaluation Kits 1

reference details image

MAX16137EVKIT

Evaluation Kit for the MAX16137

zoom

MAX16137EVKIT

Evaluation Kit for the MAX16137

Evaluation Kit for the MAX16137

Features and Benefits

  • 1.71V to 5.5V Supply Voltage Range
  • Push-Button Switch to Clear OV Latch
  • Proven 2-Layer 2oz Copper PCB Layout
  • Automotive Temperature Range: -40°C and +125°C
  • Demonstrates Compact Solution Size
  • Fully Assembled and Tested

Product Detail

The MAX16137 evaluation kit (EV kit) is designed to evaluate the MAX1613700/VY+, a 1% accuracy, windowdetector supervisory reset IC with BIST (Built-In-Self-Test) capability and overvoltage fault output in an 8-pin TDFN package. Several test points are provided to facilitate device evaluation. The EV kit is fully assembled and tested over the automotive temperature range of -40°C and +125°C and is available with the MAX1613700/VY+ installed.

Applications

  • Advanced Driver-Assistance Systems (ADAS)
  • Multivoltage ASICs
  • Servers
  • Storage Equipment
