MAX1535B: Highly Integrated Level 2 SMBus Battery Chargers Data Sheet (Rev. 2)12/16/2005527K
Product Lifecycle Obsolete
The models in this product family are no longer available.
To find replacement products for this part:
Rochester Electronics and Arrow Supply Assurance have partnered with Analog Devices to source products that have been previously discontinued or have become obsolete.
Evaluation Kits (1)
The MAX1535B evaluation kit (EV kit) is an efficient, multichemistry battery charger. It uses the Intel® System Management Bus (SMBus) to control the battery regulation voltage, charger current output, and input current-limit set point.
The MAX1535B EV kit can charge one, two, three, or four series Li+ cells with a current up to 8A.
The MAX1535B evaluation system (EV system) consists of a MAX1535B EV kit and the Maxim SMBUSMON board. The MAX1535B EV kit includes Windows® 95-/98-/2000-/XP-compatible software to provide a user-friendly interface.
- Notebook and Subnotebook Computers
- Portable Equipment with Rechargeable Batteries
- Tablet PCs
Features & Benefits
Documentation & Resources
MAX1535 Reliability Data1/12/202334K
ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal.
