MAX15095D

2.7V to 18V, 6.6A Integrated Hot-Swap/Electronic Circuit Breaker

Show More showmore-icon

2.7V to 18V Input, Smallest 6A Hot-Swap Solution with Only 12mΩ RDSON and 10% Circuit Breaker Threshold Accuracy

Info: : PRODUCTION tooltip
Info: : PRODUCTION tooltip
Part Models 2
1ku List Price Starting From $2.92
Features
  • Integration Reduces Solution Size for Blade Servers and Other Space-Constrained Designs
    • Integrated 10.6mΩ (typ) Internal Power MOSFET
    • Programmable Overvoltage Protection and Undervoltage-Lockout Threshold
    • Drive-Present Signal Input (Active-Low PRSNT pin)
    • Thermal Protection
  • Flexibility Enables Use in Many Unique Designs
    • 2.7V to 18V Operating Voltage Range
    • Programmable Inrush Current Control Under SOA Operation
    • Adjustable Circuit-Breaker Current/Current-Limit Threshold
    • Programmable Slew-Rate Control
    • Variable-Speed Circuit-Breaker Response
    • Latchoff (MAX15095) or Automatic Retry (MAX15095A) Options
  • Safety Features Ensure Accurate, Robust Protection
    • 6.6A (max) Load Current Capability
    • ±10% Circuit-Breaker Threshold Accuracy
    • IN-to-OUT Short-Circuit Detection
    • Open-Drain PG Output
    • Output Discharge After a Fault Event (MAX15095D Only)
    • Programmable Additional Delay (2µs max) to Fast-Comparator Response Time
    • Enable Input (EN)
Additional Details
show more Icon

The MAX15095 family of devices are integrated solutions for hot-swap applications requiring the safe insertion and removal of circuit line cards from a live backplane. They can also be used as electronics circuit breaker for hard drive and solid-state drive and fans. The devices integrate a hot-swap controller (10.6mΩ typ) power MOSFET, and an electronic circuit-breaker protection in a single package.

The devices are designed for protection of 2.7V to 18V supply voltages. These devices implement a foldback current limit during startup to control inrush current, lowering di/dt and keeping the MOSFET operating under safe operating area (SOA) conditions. After the startup cycle is complete, on-chip comparators provide VariableSpeed/BiLevel™ protection against short-circuit and overcurrent faults, and immunity against system noise and load transients. The load is disconnected in the event of a fault condition. The devices are factory calibrated to deliver accurate overcurrent protection with ±10% accuracy. During a fault condition, PG goes low and the devices latch off (MAX15095) or automatic retry (MAX15095A); the output could also be discharged after a fault event (MAX15095D).

The devices feature an IN-to-OUT short-circuit detection before startup. The devices provide a power-MOSFET GATE pin to program the slew rate during startup by adding an external capacitor. The devices have an undervoltage/overvoltage input pin (UVOV) that can detect an undervoltage/overvoltage fault and disconnect the IN from the OUT. Additional features include internal overtemperature protection and a power-good output (PG).

The devices are available in a 12-pin, 2.5mm x 2.5mm Flip Chip 2 QFN package (FC2QFN) and are rated over the -40°C to +105°C extended temperature range.

Applications

  • Blade Servers
  • Disk Drive Power
  • Industrial Applications
  • RAID Systems
  • Server I/O Cards
  • Storage Applications
Part Models 2
1ku List Price Starting From $2.92

close icon

Documentation

Video

Part Model Pin/Package Drawing Documentation CAD Symbols, Footprints, and 3D Models
MAX15095DGFC+
  • HTML
  • HTML
MAX15095DGFC+T
  • HTML
  • HTML

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Oct 14, 2021

- 2080A

DESIGN,ELECTRICAL DA

MAX15095DGFC+

PRODUCTION

MAX15095DGFC+T

PRODUCTION

Filter by Model

reset

Reset Filters

Part Models

Product Lifecycle

PCN

Oct 14, 2021

- 2080A

arrow down

DESIGN,ELECTRICAL DA

MAX15095DGFC+

PRODUCTION

MAX15095DGFC+T

PRODUCTION

Software & Part Ecosystem

Evaluation Kits 1

MAX15095AEVKIT

Evaluation Kit for the MAX15095A/MAX15095/MAX15095D

zoom

MAX15095AEVKIT

Evaluation Kit for the MAX15095A/MAX15095/MAX15095D

Evaluation Kit for the MAX15095A/MAX15095/MAX15095D

Features and Benefits

  • 2.7V to 18V Operating Voltage Range
  • Up to 6.6A Configurable Load Current Capability
  • Banana Jacks for Input and Output Voltage
  • Programmable Slew-Rate Control
  • Selectable/Configurable Circuit-Breaker Threshold
  • Configurable Overvoltage/Undervoltage Lockout
  • Programmable Fast Comparator Response
  • PG Output
  • Defined Safe Operation Area
  • Proven PCB Layout
  • Fully Assembled and Tested

Product Detail

The MAX15095A evaluation kit (EV kit) provides a proven design to evaluate the MAX15095A hot-swap controller with an integrated 6.6A MOSFET. The EV kit is configured to pass 6.6A in a 2.7V to 18V hot-swap application, thus providing a fully integrated solution. The EV kit uses the MAX15095AGFC+ in a 2.5mm X 2.5mm, 12-pin, 0.5mm pitch FC2QFN package with a proven four-layer PCB design. As configured, the EV kit is optimized to operate at 12V.

The EV kit can be used to evaluate all MAX15095 and MAX15095D variants.

Applications

  • Blade Servers
  • Disk Drive Power
  • Industrial Applications
  • RAID Systems
  • Server I/O Cards
  • Storage Applications

Tools & Simulations 1

LTspice® is a powerful, fast and free simulation software, schematic capture and waveform viewer with enhancements and models for improving the simulation of analog circuits.

To launch ready-to-run LTspice demonstration circuits for this part:

Step 1: Download and install LTspice on your computer.

Step 2: Click on the link in the section below to download a demonstration circuit.

Step 3: If LTspice does not automatically open after clicking the link below, you can instead run the simulation by right clicking on the link and selecting “Save Target As.” After saving the file to your computer, start LTspice and open the demonstration circuit by selecting ‘Open’ from the ‘File’ menu.
