MAX14748

PRODUCTION

USB Type-C Charger

Single-Chip USB Type-C Charging and Charger Detection Solution for 2s Li+ Battery Packs

Data Sheet (Rev. 8) Product Selection Table

Part Models: 4
1ku List Price: Starting From $4.45

Viewing:

Overview

Minimize Power Management Footprint Through High Integration
- 13mΩ (typ) Integrated Battery To System Switch
- Thermal Current Limiting
- DC-DC Converter with Boost and Reverse Buck
- High Efficiency
  - 92% in Boost Mode at 1A Output Current and 7.4V Battery Voltage
  - 94% in Reverse Buck Mode at 500mA Output
- Internal USB Switch for USB D+/D- Data Lines
Easy-to-Implement Li+ Battery Charging
- Charges 2s Li-Ion Batteries from Legacy 5V USB Adapters
  - 15W Input Power with 3A Type-C Adapter
  - 7.5W Input Power with DCP Adapter
  - 1A System/Charge Current From DCP Adapter
  - 2A System/Charge Current From 3A Type-C Adapter
- DRP Mode USB Type-C Specification, Rev 1.1 Compliant
- UFP Mode USB Type-C Specification, Rev 1.1 Support
- V_CONN and Super-Speed Multiplexer Logic Controls
- Non-Standard DCP Detection
- USB Battery Charging Specification, Rev 1.2 Compliant
Automatic Input Current Limit (AICL) Power Management
Support Weak/Dead Batteries Detection
- Smart Power Selector
- Thermistor Monitor
Various Protection Features
- 28V Integrated Overvoltage Protection
- JEITA Charge Protection
- ±15kV ESD Protection on USB Adapter Pins

The MAX14748 USB battery charger integrates a charger detector, boost/buck converter, and Li+ battery charger with smart power selector to provide fast and safe charging of 2s Li+ battery packs.

The MAX14748 provides support for devices functioning as a UFP/DRP per the USB Type-C 1.1 standard, while also providing detection of legacy USB Battery Charging Specification, Revision 1.2 (BC1.2) compliant chargers in addition to other nonstandard chargers. The programmable Automatic Input Current Limiting (AICL) feature ensures that maximum safe current is drawn from the charging adapter.

The Li+ charger includes an automatic Smart Power Selector^™ to simultaneously charge the battery and provide power to the system load. The Smart Power Selector function will supplement the system power with the battery if power from the charging adapter is insufficient. The Li+ charger features JEITA thermal monitoring and charger voltage/current reduction or charger disable.

The MAX14748 is available in a 54-bump, 0.4mm pitch, 3.97mm x 2.77mm x 0.64mm wafer-level package (WLP) and operates over the -40°C to +85°C extended temperature range.

Applications

Digital Imaging (DSC, DVC)
Handheld Barcode Readers
Wireless Speakers

Part Models: 4
1ku List Price: Starting From $4.45

Documentation

ADI has always placed the highest emphasis on delivering products that meet the maximum levels of quality and reliability. We achieve this by incorporating quality and reliability checks in every scope of product and process design, and in the manufacturing process as well. "Zero defects" for shipped products is always our goal. View our quality and reliability program and certifications for more information.

Part Model	Pin/Package Drawing	Documentation	CAD Symbols, Footprints, and 3D Models
MAX14748BEWW+	54-WLCSP-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX14748BEWW+T	54-WLCSP-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX14748EWW+	54-WLCSP-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys
MAX14748EWW+T	54-WLCSP-N/A	Material Declaration Reliablity Data Package Resources	Ultra Librarian SamacSys

Part Models	Product Lifecycle	PCN

Jan 28, 2021 - 2123 TEST
		pcn_2123
MAX14748BEWW+	PRODUCTION
MAX14748BEWW+T	PRODUCTION
Jul 11, 2019 - 1952 WAFER FAB
		pcn_1952
MAX14748BEWW+	PRODUCTION
MAX14748BEWW+T	PRODUCTION

This is the most up-to-date revision of the Data Sheet.

Software Resources

Can't find the software or driver you need?

Request a Driver/Software

Tools & Simulations

Software Development 1

MAX14748 EV Kit Tool, 1.0.1

Evaluation Kits

Evaluation Kit for the MAX14748

Buy Now View Details

Features and Benefits

RoHS Compliant
Proven PCB Layout
Full Assembled and Tested
I²C Serial Interface

Product Details

The MAX14748 evaluation kit (EV kit) is a fully assembled and tested circuit for evaluating the MAX14748 USB Type-C charger. Refer to the MAX14748 IC data sheet for detailed information regarding the operation and features of the devices.

For additional information, please refer to the MAX14748 user guide.
